Go to the source code of this file.
Macros | |
| #define | FLASH_FMA 0x400FD000 |
| #define | FLASH_FMD 0x400FD004 |
| #define | FLASH_FMC 0x400FD008 |
| #define | FLASH_FCRIS 0x400FD00C |
| #define | FLASH_FCIM 0x400FD010 |
| #define | FLASH_FCMISC 0x400FD014 |
| #define | FLASH_FMC2 0x400FD020 |
| #define | FLASH_FWBVAL 0x400FD030 |
| #define | FLASH_FLPEKEY 0x400FD03C |
| #define | FLASH_FWBN 0x400FD100 |
| #define | FLASH_PP 0x400FDFC0 |
| #define | FLASH_FSIZE 0x400FDFC0 |
| #define | FLASH_SSIZE 0x400FDFC4 |
| #define | FLASH_CONF 0x400FDFC8 |
| #define | FLASH_ROMSWMAP 0x400FDFCC |
| #define | FLASH_DMASZ 0x400FDFD0 |
| #define | FLASH_DMAST 0x400FDFD4 |
| #define | FLASH_RVP 0x400FE0D4 |
| #define | FLASH_RMCTL 0x400FE0F0 |
| #define | FLASH_BOOTCFG 0x400FE1D0 |
| #define | FLASH_USERREG0 0x400FE1E0 |
| #define | FLASH_USERREG1 0x400FE1E4 |
| #define | FLASH_USERREG2 0x400FE1E8 |
| #define | FLASH_USERREG3 0x400FE1EC |
| #define | FLASH_FMPRE0 0x400FE200 |
| #define | FLASH_FMPRE1 0x400FE204 |
| #define | FLASH_FMPRE2 0x400FE208 |
| #define | FLASH_FMPRE3 0x400FE20C |
| #define | FLASH_FMPRE4 0x400FE210 |
| #define | FLASH_FMPRE5 0x400FE214 |
| #define | FLASH_FMPRE6 0x400FE218 |
| #define | FLASH_FMPRE7 0x400FE21C |
| #define | FLASH_FMPRE8 0x400FE220 |
| #define | FLASH_FMPRE9 0x400FE224 |
| #define | FLASH_FMPRE10 0x400FE228 |
| #define | FLASH_FMPRE11 0x400FE22C |
| #define | FLASH_FMPRE12 0x400FE230 |
| #define | FLASH_FMPRE13 0x400FE234 |
| #define | FLASH_FMPRE14 0x400FE238 |
| #define | FLASH_FMPRE15 0x400FE23C |
| #define | FLASH_FMPPE0 0x400FE400 |
| #define | FLASH_FMPPE1 0x400FE404 |
| #define | FLASH_FMPPE2 0x400FE408 |
| #define | FLASH_FMPPE3 0x400FE40C |
| #define | FLASH_FMPPE4 0x400FE410 |
| #define | FLASH_FMPPE5 0x400FE414 |
| #define | FLASH_FMPPE6 0x400FE418 |
| #define | FLASH_FMPPE7 0x400FE41C |
| #define | FLASH_FMPPE8 0x400FE420 |
| #define | FLASH_FMPPE9 0x400FE424 |
| #define | FLASH_FMPPE10 0x400FE428 |
| #define | FLASH_FMPPE11 0x400FE42C |
| #define | FLASH_FMPPE12 0x400FE430 |
| #define | FLASH_FMPPE13 0x400FE434 |
| #define | FLASH_FMPPE14 0x400FE438 |
| #define | FLASH_FMPPE15 0x400FE43C |
| #define | FLASH_FMA_OFFSET_M 0x000FFFFF |
| #define | FLASH_FMA_OFFSET_S 0 |
| #define | FLASH_FMD_DATA_M 0xFFFFFFFF |
| #define | FLASH_FMD_DATA_S 0 |
| #define | FLASH_FMC_WRKEY 0xA4420000 |
| #define | FLASH_FMC_COMT 0x00000008 |
| #define | FLASH_FMC_MERASE 0x00000004 |
| #define | FLASH_FMC_ERASE 0x00000002 |
| #define | FLASH_FMC_WRITE 0x00000001 |
| #define | FLASH_FCRIS_PROGRIS 0x00002000 |
| #define | FLASH_FCRIS_ERRIS 0x00000800 |
| #define | FLASH_FCRIS_INVDRIS 0x00000400 |
| #define | FLASH_FCRIS_VOLTRIS 0x00000200 |
| #define | FLASH_FCRIS_ERIS 0x00000004 |
| #define | FLASH_FCRIS_PRIS 0x00000002 |
| #define | FLASH_FCRIS_ARIS 0x00000001 |
| #define | FLASH_FCIM_PROGMASK 0x00002000 |
| #define | FLASH_FCIM_ERMASK 0x00000800 |
| #define | FLASH_FCIM_INVDMASK 0x00000400 |
| #define | FLASH_FCIM_VOLTMASK 0x00000200 |
| #define | FLASH_FCIM_EMASK 0x00000004 |
| #define | FLASH_FCIM_PMASK 0x00000002 |
| #define | FLASH_FCIM_AMASK 0x00000001 |
| #define | FLASH_FCMISC_PROGMISC 0x00002000 |
| #define | FLASH_FCMISC_ERMISC 0x00000800 |
| #define | FLASH_FCMISC_INVDMISC 0x00000400 |
| #define | FLASH_FCMISC_VOLTMISC 0x00000200 |
| #define | FLASH_FCMISC_EMISC 0x00000004 |
| #define | FLASH_FCMISC_PMISC 0x00000002 |
| #define | FLASH_FCMISC_AMISC 0x00000001 |
| #define | FLASH_FMC2_WRKEY 0xA4420000 |
| #define | FLASH_FMC2_WRBUF 0x00000001 |
| #define | FLASH_FWBVAL_FWB_M 0xFFFFFFFF |
| #define | FLASH_FLPEKEY_PEKEY_M 0x0000FFFF |
| #define | FLASH_FLPEKEY_PEKEY_S 0 |
| #define | FLASH_FWBN_DATA_M 0xFFFFFFFF |
| #define | FLASH_PP_PFC 0x40000000 |
| #define | FLASH_PP_FMM 0x20000000 |
| #define | FLASH_PP_DFA 0x10000000 |
| #define | FLASH_PP_EESS_M 0x00780000 |
| #define | FLASH_PP_EESS_1KB 0x00000000 |
| #define | FLASH_PP_EESS_2KB 0x00080000 |
| #define | FLASH_PP_EESS_4KB 0x00100000 |
| #define | FLASH_PP_EESS_8KB 0x00180000 |
| #define | FLASH_PP_MAINSS_M 0x00070000 |
| #define | FLASH_PP_MAINSS_1KB 0x00000000 |
| #define | FLASH_PP_MAINSS_2KB 0x00010000 |
| #define | FLASH_PP_MAINSS_4KB 0x00020000 |
| #define | FLASH_PP_MAINSS_8KB 0x00030000 |
| #define | FLASH_PP_MAINSS_16KB 0x00040000 |
| #define | FLASH_PP_SIZE_M 0x0000FFFF |
| #define | FLASH_PP_SIZE_512KB 0x000000FF |
| #define | FLASH_PP_SIZE_1MB 0x000001FF |
| #define | FLASH_FSIZE_SIZE_M 0x0000FFFF |
| #define | FLASH_FSIZE_SIZE_32KB 0x0000000F |
| #define | FLASH_FSIZE_SIZE_64KB 0x0000001F |
| #define | FLASH_FSIZE_SIZE_128KB 0x0000003F |
| #define | FLASH_FSIZE_SIZE_256KB 0x0000007F |
| #define | FLASH_SSIZE_SIZE_M 0x0000FFFF |
| #define | FLASH_SSIZE_SIZE_12KB 0x0000002F |
| #define | FLASH_SSIZE_SIZE_24KB 0x0000005F |
| #define | FLASH_SSIZE_SIZE_32KB 0x0000007F |
| #define | FLASH_SSIZE_SIZE_256KB 0x000003FF |
| #define | FLASH_CONF_FMME 0x40000000 |
| #define | FLASH_CONF_SPFE 0x20000000 |
| #define | FLASH_CONF_CLRTV 0x00100000 |
| #define | FLASH_CONF_FPFON 0x00020000 |
| #define | FLASH_CONF_FPFOFF 0x00010000 |
| #define | FLASH_ROMSWMAP_SAFERTOS 0x00000001 |
| #define | FLASH_ROMSWMAP_SW0EN_M 0x00000003 |
| #define | FLASH_ROMSWMAP_SW0EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW0EN_CORE 0x00000001 |
| #define | FLASH_ROMSWMAP_SW1EN_M 0x0000000C |
| #define | FLASH_ROMSWMAP_SW1EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW1EN_CORE 0x00000004 |
| #define | FLASH_ROMSWMAP_SW2EN_M 0x00000030 |
| #define | FLASH_ROMSWMAP_SW2EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW2EN_CORE 0x00000010 |
| #define | FLASH_ROMSWMAP_SW3EN_M 0x000000C0 |
| #define | FLASH_ROMSWMAP_SW3EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW3EN_CORE 0x00000040 |
| #define | FLASH_ROMSWMAP_SW4EN_M 0x00000300 |
| #define | FLASH_ROMSWMAP_SW4EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW4EN_CORE 0x00000100 |
| #define | FLASH_ROMSWMAP_SW5EN_M 0x00000C00 |
| #define | FLASH_ROMSWMAP_SW5EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW5EN_CORE 0x00000400 |
| #define | FLASH_ROMSWMAP_SW6EN_M 0x00003000 |
| #define | FLASH_ROMSWMAP_SW6EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW6EN_CORE 0x00001000 |
| #define | FLASH_ROMSWMAP_SW7EN_M 0x0000C000 |
| #define | FLASH_ROMSWMAP_SW7EN_NOTVIS 0x00000000 |
| #define | FLASH_ROMSWMAP_SW7EN_CORE 0x00004000 |
| #define | FLASH_DMASZ_SIZE_M 0x0003FFFF |
| #define | FLASH_DMASZ_SIZE_S 0 |
| #define | FLASH_DMAST_ADDR_M 0x1FFFF800 |
| #define | FLASH_DMAST_ADDR_S 11 |
| #define | FLASH_RVP_RV_M 0xFFFFFFFF |
| #define | FLASH_RVP_RV_S 0 |
| #define | FLASH_RMCTL_BA 0x00000001 |
| #define | FLASH_BOOTCFG_NW 0x80000000 |
| #define | FLASH_BOOTCFG_PORT_M 0x0000E000 |
| #define | FLASH_BOOTCFG_PORT_A 0x00000000 |
| #define | FLASH_BOOTCFG_PORT_B 0x00002000 |
| #define | FLASH_BOOTCFG_PORT_C 0x00004000 |
| #define | FLASH_BOOTCFG_PORT_D 0x00006000 |
| #define | FLASH_BOOTCFG_PORT_E 0x00008000 |
| #define | FLASH_BOOTCFG_PORT_F 0x0000A000 |
| #define | FLASH_BOOTCFG_PORT_G 0x0000C000 |
| #define | FLASH_BOOTCFG_PORT_H 0x0000E000 |
| #define | FLASH_BOOTCFG_PIN_M 0x00001C00 |
| #define | FLASH_BOOTCFG_PIN_0 0x00000000 |
| #define | FLASH_BOOTCFG_PIN_1 0x00000400 |
| #define | FLASH_BOOTCFG_PIN_2 0x00000800 |
| #define | FLASH_BOOTCFG_PIN_3 0x00000C00 |
| #define | FLASH_BOOTCFG_PIN_4 0x00001000 |
| #define | FLASH_BOOTCFG_PIN_5 0x00001400 |
| #define | FLASH_BOOTCFG_PIN_6 0x00001800 |
| #define | FLASH_BOOTCFG_PIN_7 0x00001C00 |
| #define | FLASH_BOOTCFG_POL 0x00000200 |
| #define | FLASH_BOOTCFG_EN 0x00000100 |
| #define | FLASH_BOOTCFG_KEY 0x00000010 |
| #define | FLASH_BOOTCFG_DBG1 0x00000002 |
| #define | FLASH_BOOTCFG_DBG0 0x00000001 |
| #define | FLASH_USERREG0_DATA_M 0xFFFFFFFF |
| #define | FLASH_USERREG0_DATA_S 0 |
| #define | FLASH_USERREG1_DATA_M 0xFFFFFFFF |
| #define | FLASH_USERREG1_DATA_S 0 |
| #define | FLASH_USERREG2_DATA_M 0xFFFFFFFF |
| #define | FLASH_USERREG2_DATA_S 0 |
| #define | FLASH_USERREG3_DATA_M 0xFFFFFFFF |
| #define | FLASH_USERREG3_DATA_S 0 |
| #define | FLASH_FMPRE8_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE8_READ_ENABLE_S 0 |
| #define | FLASH_FMPRE9_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE9_READ_ENABLE_S 0 |
| #define | FLASH_FMPRE10_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE10_READ_ENABLE_S 0 |
| #define | FLASH_FMPRE11_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE11_READ_ENABLE_S 0 |
| #define | FLASH_FMPRE12_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE12_READ_ENABLE_S 0 |
| #define | FLASH_FMPRE13_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE13_READ_ENABLE_S 0 |
| #define | FLASH_FMPRE14_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE14_READ_ENABLE_S 0 |
| #define | FLASH_FMPRE15_READ_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPRE15_READ_ENABLE_S 0 |
| #define | FLASH_FMPPE8_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE8_PROG_ENABLE_S 0 |
| #define | FLASH_FMPPE9_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE9_PROG_ENABLE_S 0 |
| #define | FLASH_FMPPE10_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE10_PROG_ENABLE_S 0 |
| #define | FLASH_FMPPE11_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE11_PROG_ENABLE_S 0 |
| #define | FLASH_FMPPE12_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE12_PROG_ENABLE_S 0 |
| #define | FLASH_FMPPE13_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE13_PROG_ENABLE_S 0 |
| #define | FLASH_FMPPE14_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE14_PROG_ENABLE_S 0 |
| #define | FLASH_FMPPE15_PROG_ENABLE_M 0xFFFFFFFF |
| #define | FLASH_FMPPE15_PROG_ENABLE_S 0 |
| #define | FLASH_PROTECT_SIZE 0x00000800 |
| #define | FLASH_ERASE_SIZE 0x00000400 |
| #define FLASH_BOOTCFG 0x400FE1D0 |
Definition at line 69 of file hw_flash.h.
| #define FLASH_BOOTCFG_DBG0 0x00000001 |
Definition at line 421 of file hw_flash.h.
| #define FLASH_BOOTCFG_DBG1 0x00000002 |
Definition at line 420 of file hw_flash.h.
| #define FLASH_BOOTCFG_EN 0x00000100 |
Definition at line 418 of file hw_flash.h.
| #define FLASH_BOOTCFG_KEY 0x00000010 |
Definition at line 419 of file hw_flash.h.
| #define FLASH_BOOTCFG_NW 0x80000000 |
Definition at line 398 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_0 0x00000000 |
Definition at line 409 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_1 0x00000400 |
Definition at line 410 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_2 0x00000800 |
Definition at line 411 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_3 0x00000C00 |
Definition at line 412 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_4 0x00001000 |
Definition at line 413 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_5 0x00001400 |
Definition at line 414 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_6 0x00001800 |
Definition at line 415 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_7 0x00001C00 |
Definition at line 416 of file hw_flash.h.
| #define FLASH_BOOTCFG_PIN_M 0x00001C00 |
Definition at line 408 of file hw_flash.h.
| #define FLASH_BOOTCFG_POL 0x00000200 |
Definition at line 417 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_A 0x00000000 |
Definition at line 400 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_B 0x00002000 |
Definition at line 401 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_C 0x00004000 |
Definition at line 402 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_D 0x00006000 |
Definition at line 403 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_E 0x00008000 |
Definition at line 404 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_F 0x0000A000 |
Definition at line 405 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_G 0x0000C000 |
Definition at line 406 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_H 0x0000E000 |
Definition at line 407 of file hw_flash.h.
| #define FLASH_BOOTCFG_PORT_M 0x0000E000 |
Definition at line 399 of file hw_flash.h.
| #define FLASH_CONF 0x400FDFC8 |
Definition at line 63 of file hw_flash.h.
| #define FLASH_CONF_CLRTV 0x00100000 |
Definition at line 300 of file hw_flash.h.
| #define FLASH_CONF_FMME 0x40000000 |
Definition at line 298 of file hw_flash.h.
| #define FLASH_CONF_FPFOFF 0x00010000 |
Definition at line 302 of file hw_flash.h.
| #define FLASH_CONF_FPFON 0x00020000 |
Definition at line 301 of file hw_flash.h.
| #define FLASH_CONF_SPFE 0x20000000 |
Definition at line 299 of file hw_flash.h.
| #define FLASH_DMAST 0x400FDFD4 |
Definition at line 66 of file hw_flash.h.
| #define FLASH_DMAST_ADDR_M 0x1FFFF800 |
Definition at line 372 of file hw_flash.h.
| #define FLASH_DMAST_ADDR_S 11 |
Definition at line 376 of file hw_flash.h.
| #define FLASH_DMASZ 0x400FDFD0 |
Definition at line 65 of file hw_flash.h.
| #define FLASH_DMASZ_SIZE_M 0x0003FFFF |
Definition at line 364 of file hw_flash.h.
| #define FLASH_DMASZ_SIZE_S 0 |
Definition at line 365 of file hw_flash.h.
| #define FLASH_ERASE_SIZE 0x00000400 |
Definition at line 623 of file hw_flash.h.
Referenced by FlashErase().
| #define FLASH_FCIM 0x400FD010 |
Definition at line 53 of file hw_flash.h.
Referenced by EEPROMIntDisable(), EEPROMIntEnable(), FlashIntDisable(), and FlashIntEnable().
| #define FLASH_FCIM_AMASK 0x00000001 |
Definition at line 194 of file hw_flash.h.
| #define FLASH_FCIM_EMASK 0x00000004 |
Definition at line 192 of file hw_flash.h.
Referenced by EEPROMIntDisable().
| #define FLASH_FCIM_ERMASK 0x00000800 |
Definition at line 189 of file hw_flash.h.
| #define FLASH_FCIM_INVDMASK 0x00000400 |
Definition at line 190 of file hw_flash.h.
| #define FLASH_FCIM_PMASK 0x00000002 |
Definition at line 193 of file hw_flash.h.
| #define FLASH_FCIM_PROGMASK 0x00002000 |
Definition at line 188 of file hw_flash.h.
| #define FLASH_FCIM_VOLTMASK 0x00000200 |
Definition at line 191 of file hw_flash.h.
| #define FLASH_FCMISC 0x400FD014 |
Definition at line 54 of file hw_flash.h.
Referenced by EEPROMIntClear(), EEPROMIntStatus(), FlashErase(), FlashIntClear(), FlashIntStatus(), and FlashProgram().
| #define FLASH_FCMISC_AMISC 0x00000001 |
Definition at line 213 of file hw_flash.h.
Referenced by FlashErase(), and FlashProgram().
| #define FLASH_FCMISC_EMISC 0x00000004 |
Definition at line 209 of file hw_flash.h.
Referenced by EEPROMIntClear(), and EEPROMIntStatus().
| #define FLASH_FCMISC_ERMISC 0x00000800 |
Definition at line 203 of file hw_flash.h.
Referenced by FlashErase().
| #define FLASH_FCMISC_INVDMISC 0x00000400 |
Definition at line 205 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FCMISC_PMISC 0x00000002 |
Definition at line 211 of file hw_flash.h.
| #define FLASH_FCMISC_PROGMISC 0x00002000 |
Definition at line 201 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FCMISC_VOLTMISC 0x00000200 |
Definition at line 207 of file hw_flash.h.
Referenced by FlashErase(), and FlashProgram().
| #define FLASH_FCRIS 0x400FD00C |
Definition at line 51 of file hw_flash.h.
Referenced by FlashErase(), FlashIntStatus(), and FlashProgram().
| #define FLASH_FCRIS_ARIS 0x00000001 |
Definition at line 181 of file hw_flash.h.
Referenced by FlashErase(), and FlashProgram().
| #define FLASH_FCRIS_ERIS 0x00000004 |
Definition at line 179 of file hw_flash.h.
Referenced by EEPROMIntEnable().
| #define FLASH_FCRIS_ERRIS 0x00000800 |
Definition at line 173 of file hw_flash.h.
Referenced by FlashErase().
| #define FLASH_FCRIS_INVDRIS 0x00000400 |
Definition at line 175 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FCRIS_PRIS 0x00000002 |
Definition at line 180 of file hw_flash.h.
| #define FLASH_FCRIS_PROGRIS 0x00002000 |
Definition at line 171 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FCRIS_VOLTRIS 0x00000200 |
Definition at line 177 of file hw_flash.h.
Referenced by FlashErase(), and FlashProgram().
| #define FLASH_FLPEKEY 0x400FD03C |
Definition at line 58 of file hw_flash.h.
| #define FLASH_FLPEKEY_PEKEY_M 0x0000FFFF |
Definition at line 236 of file hw_flash.h.
| #define FLASH_FLPEKEY_PEKEY_S 0 |
Definition at line 237 of file hw_flash.h.
| #define FLASH_FMA 0x400FD000 |
Definition at line 48 of file hw_flash.h.
Referenced by FlashErase(), FlashProgram(), FlashProtectSave(), and FlashUserSave().
| #define FLASH_FMA_OFFSET_M 0x000FFFFF |
Definition at line 144 of file hw_flash.h.
| #define FLASH_FMA_OFFSET_S 0 |
Definition at line 145 of file hw_flash.h.
| #define FLASH_FMC 0x400FD008 |
Definition at line 50 of file hw_flash.h.
Referenced by FlashErase(), FlashProtectSave(), and FlashUserSave().
| #define FLASH_FMC2 0x400FD020 |
Definition at line 56 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FMC2_WRBUF 0x00000001 |
Definition at line 222 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FMC2_WRKEY 0xA4420000 |
Definition at line 221 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FMC_COMT 0x00000008 |
Definition at line 161 of file hw_flash.h.
Referenced by FlashProtectSave(), and FlashUserSave().
| #define FLASH_FMC_ERASE 0x00000002 |
Definition at line 163 of file hw_flash.h.
Referenced by FlashErase().
| #define FLASH_FMC_MERASE 0x00000004 |
Definition at line 162 of file hw_flash.h.
| #define FLASH_FMC_WRITE 0x00000001 |
Definition at line 164 of file hw_flash.h.
| #define FLASH_FMC_WRKEY 0xA4420000 |
Definition at line 160 of file hw_flash.h.
Referenced by FlashErase(), FlashProtectSave(), and FlashUserSave().
| #define FLASH_FMD 0x400FD004 |
Definition at line 49 of file hw_flash.h.
| #define FLASH_FMD_DATA_M 0xFFFFFFFF |
Definition at line 152 of file hw_flash.h.
| #define FLASH_FMD_DATA_S 0 |
Definition at line 153 of file hw_flash.h.
| #define FLASH_FMPPE0 0x400FE400 |
Definition at line 106 of file hw_flash.h.
| #define FLASH_FMPPE1 0x400FE404 |
Definition at line 108 of file hw_flash.h.
| #define FLASH_FMPPE10 0x400FE428 |
Definition at line 126 of file hw_flash.h.
| #define FLASH_FMPPE10_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 560 of file hw_flash.h.
| #define FLASH_FMPPE10_PROG_ENABLE_S 0 |
Definition at line 562 of file hw_flash.h.
| #define FLASH_FMPPE11 0x400FE42C |
Definition at line 128 of file hw_flash.h.
| #define FLASH_FMPPE11_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 570 of file hw_flash.h.
| #define FLASH_FMPPE11_PROG_ENABLE_S 0 |
Definition at line 572 of file hw_flash.h.
| #define FLASH_FMPPE12 0x400FE430 |
Definition at line 130 of file hw_flash.h.
| #define FLASH_FMPPE12_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 580 of file hw_flash.h.
| #define FLASH_FMPPE12_PROG_ENABLE_S 0 |
Definition at line 582 of file hw_flash.h.
| #define FLASH_FMPPE13 0x400FE434 |
Definition at line 132 of file hw_flash.h.
| #define FLASH_FMPPE13_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 590 of file hw_flash.h.
| #define FLASH_FMPPE13_PROG_ENABLE_S 0 |
Definition at line 592 of file hw_flash.h.
| #define FLASH_FMPPE14 0x400FE438 |
Definition at line 134 of file hw_flash.h.
| #define FLASH_FMPPE14_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 600 of file hw_flash.h.
| #define FLASH_FMPPE14_PROG_ENABLE_S 0 |
Definition at line 602 of file hw_flash.h.
| #define FLASH_FMPPE15 0x400FE43C |
Definition at line 136 of file hw_flash.h.
| #define FLASH_FMPPE15_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 610 of file hw_flash.h.
| #define FLASH_FMPPE15_PROG_ENABLE_S 0 |
Definition at line 612 of file hw_flash.h.
| #define FLASH_FMPPE2 0x400FE408 |
Definition at line 110 of file hw_flash.h.
| #define FLASH_FMPPE3 0x400FE40C |
Definition at line 112 of file hw_flash.h.
| #define FLASH_FMPPE4 0x400FE410 |
Definition at line 114 of file hw_flash.h.
| #define FLASH_FMPPE5 0x400FE414 |
Definition at line 116 of file hw_flash.h.
| #define FLASH_FMPPE6 0x400FE418 |
Definition at line 118 of file hw_flash.h.
| #define FLASH_FMPPE7 0x400FE41C |
Definition at line 120 of file hw_flash.h.
| #define FLASH_FMPPE8 0x400FE420 |
Definition at line 122 of file hw_flash.h.
| #define FLASH_FMPPE8_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 540 of file hw_flash.h.
| #define FLASH_FMPPE8_PROG_ENABLE_S 0 |
Definition at line 542 of file hw_flash.h.
| #define FLASH_FMPPE9 0x400FE424 |
Definition at line 124 of file hw_flash.h.
| #define FLASH_FMPPE9_PROG_ENABLE_M 0xFFFFFFFF |
Definition at line 550 of file hw_flash.h.
| #define FLASH_FMPPE9_PROG_ENABLE_S 0 |
Definition at line 552 of file hw_flash.h.
| #define FLASH_FMPRE0 0x400FE200 |
Definition at line 74 of file hw_flash.h.
| #define FLASH_FMPRE1 0x400FE204 |
Definition at line 76 of file hw_flash.h.
| #define FLASH_FMPRE10 0x400FE228 |
Definition at line 94 of file hw_flash.h.
| #define FLASH_FMPRE10_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 480 of file hw_flash.h.
| #define FLASH_FMPRE10_READ_ENABLE_S 0 |
Definition at line 482 of file hw_flash.h.
| #define FLASH_FMPRE11 0x400FE22C |
Definition at line 96 of file hw_flash.h.
| #define FLASH_FMPRE11_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 490 of file hw_flash.h.
| #define FLASH_FMPRE11_READ_ENABLE_S 0 |
Definition at line 492 of file hw_flash.h.
| #define FLASH_FMPRE12 0x400FE230 |
Definition at line 98 of file hw_flash.h.
| #define FLASH_FMPRE12_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 500 of file hw_flash.h.
| #define FLASH_FMPRE12_READ_ENABLE_S 0 |
Definition at line 502 of file hw_flash.h.
| #define FLASH_FMPRE13 0x400FE234 |
Definition at line 100 of file hw_flash.h.
| #define FLASH_FMPRE13_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 510 of file hw_flash.h.
| #define FLASH_FMPRE13_READ_ENABLE_S 0 |
Definition at line 512 of file hw_flash.h.
| #define FLASH_FMPRE14 0x400FE238 |
Definition at line 102 of file hw_flash.h.
| #define FLASH_FMPRE14_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 520 of file hw_flash.h.
| #define FLASH_FMPRE14_READ_ENABLE_S 0 |
Definition at line 522 of file hw_flash.h.
| #define FLASH_FMPRE15 0x400FE23C |
Definition at line 104 of file hw_flash.h.
| #define FLASH_FMPRE15_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 530 of file hw_flash.h.
| #define FLASH_FMPRE15_READ_ENABLE_S 0 |
Definition at line 532 of file hw_flash.h.
| #define FLASH_FMPRE2 0x400FE208 |
Definition at line 78 of file hw_flash.h.
| #define FLASH_FMPRE3 0x400FE20C |
Definition at line 80 of file hw_flash.h.
| #define FLASH_FMPRE4 0x400FE210 |
Definition at line 82 of file hw_flash.h.
| #define FLASH_FMPRE5 0x400FE214 |
Definition at line 84 of file hw_flash.h.
| #define FLASH_FMPRE6 0x400FE218 |
Definition at line 86 of file hw_flash.h.
| #define FLASH_FMPRE7 0x400FE21C |
Definition at line 88 of file hw_flash.h.
| #define FLASH_FMPRE8 0x400FE220 |
Definition at line 90 of file hw_flash.h.
| #define FLASH_FMPRE8_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 460 of file hw_flash.h.
| #define FLASH_FMPRE8_READ_ENABLE_S 0 |
Definition at line 462 of file hw_flash.h.
| #define FLASH_FMPRE9 0x400FE224 |
Definition at line 92 of file hw_flash.h.
| #define FLASH_FMPRE9_READ_ENABLE_M 0xFFFFFFFF |
Definition at line 470 of file hw_flash.h.
| #define FLASH_FMPRE9_READ_ENABLE_S 0 |
Definition at line 472 of file hw_flash.h.
| #define FLASH_FSIZE 0x400FDFC0 |
Definition at line 61 of file hw_flash.h.
| #define FLASH_FSIZE_SIZE_128KB 0x0000003F |
Definition at line 279 of file hw_flash.h.
| #define FLASH_FSIZE_SIZE_256KB 0x0000007F |
Definition at line 280 of file hw_flash.h.
| #define FLASH_FSIZE_SIZE_32KB 0x0000000F |
Definition at line 277 of file hw_flash.h.
| #define FLASH_FSIZE_SIZE_64KB 0x0000001F |
Definition at line 278 of file hw_flash.h.
| #define FLASH_FSIZE_SIZE_M 0x0000FFFF |
Definition at line 276 of file hw_flash.h.
| #define FLASH_FWBN 0x400FD100 |
Definition at line 59 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FWBN_DATA_M 0xFFFFFFFF |
Definition at line 244 of file hw_flash.h.
| #define FLASH_FWBVAL 0x400FD030 |
Definition at line 57 of file hw_flash.h.
Referenced by FlashProgram().
| #define FLASH_FWBVAL_FWB_M 0xFFFFFFFF |
Definition at line 229 of file hw_flash.h.
| #define FLASH_PP 0x400FDFC0 |
Definition at line 60 of file hw_flash.h.
Referenced by SysCtlFlashSectorSizeGet(), and SysCtlFlashSizeGet().
| #define FLASH_PP_DFA 0x10000000 |
Definition at line 253 of file hw_flash.h.
| #define FLASH_PP_EESS_1KB 0x00000000 |
Definition at line 256 of file hw_flash.h.
| #define FLASH_PP_EESS_2KB 0x00080000 |
Definition at line 257 of file hw_flash.h.
| #define FLASH_PP_EESS_4KB 0x00100000 |
Definition at line 258 of file hw_flash.h.
| #define FLASH_PP_EESS_8KB 0x00180000 |
Definition at line 259 of file hw_flash.h.
| #define FLASH_PP_EESS_M 0x00780000 |
Definition at line 254 of file hw_flash.h.
| #define FLASH_PP_FMM 0x20000000 |
Definition at line 252 of file hw_flash.h.
| #define FLASH_PP_MAINSS_16KB 0x00040000 |
Definition at line 266 of file hw_flash.h.
| #define FLASH_PP_MAINSS_1KB 0x00000000 |
Definition at line 262 of file hw_flash.h.
| #define FLASH_PP_MAINSS_2KB 0x00010000 |
Definition at line 263 of file hw_flash.h.
| #define FLASH_PP_MAINSS_4KB 0x00020000 |
Definition at line 264 of file hw_flash.h.
| #define FLASH_PP_MAINSS_8KB 0x00030000 |
Definition at line 265 of file hw_flash.h.
| #define FLASH_PP_MAINSS_M 0x00070000 |
Definition at line 260 of file hw_flash.h.
Referenced by SysCtlFlashSectorSizeGet().
| #define FLASH_PP_PFC 0x40000000 |
Definition at line 251 of file hw_flash.h.
| #define FLASH_PP_SIZE_1MB 0x000001FF |
Definition at line 269 of file hw_flash.h.
| #define FLASH_PP_SIZE_512KB 0x000000FF |
Definition at line 268 of file hw_flash.h.
| #define FLASH_PP_SIZE_M 0x0000FFFF |
Definition at line 267 of file hw_flash.h.
Referenced by SysCtlFlashSizeGet().
| #define FLASH_PROTECT_SIZE 0x00000800 |
Definition at line 622 of file hw_flash.h.
Referenced by FlashProtectGet(), and FlashProtectSet().
| #define FLASH_RMCTL 0x400FE0F0 |
Definition at line 68 of file hw_flash.h.
| #define FLASH_RMCTL_BA 0x00000001 |
Definition at line 391 of file hw_flash.h.
| #define FLASH_ROMSWMAP 0x400FDFCC |
Definition at line 64 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SAFERTOS 0x00000001 |
Definition at line 309 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW0EN_CORE 0x00000001 |
Definition at line 314 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW0EN_M 0x00000003 |
Definition at line 310 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW0EN_NOTVIS 0x00000000 |
Definition at line 311 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW1EN_CORE 0x00000004 |
Definition at line 320 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW1EN_M 0x0000000C |
Definition at line 316 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW1EN_NOTVIS 0x00000000 |
Definition at line 317 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW2EN_CORE 0x00000010 |
Definition at line 326 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW2EN_M 0x00000030 |
Definition at line 322 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW2EN_NOTVIS 0x00000000 |
Definition at line 323 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW3EN_CORE 0x00000040 |
Definition at line 332 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW3EN_M 0x000000C0 |
Definition at line 328 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW3EN_NOTVIS 0x00000000 |
Definition at line 329 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW4EN_CORE 0x00000100 |
Definition at line 338 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW4EN_M 0x00000300 |
Definition at line 334 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW4EN_NOTVIS 0x00000000 |
Definition at line 335 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW5EN_CORE 0x00000400 |
Definition at line 344 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW5EN_M 0x00000C00 |
Definition at line 340 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW5EN_NOTVIS 0x00000000 |
Definition at line 341 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW6EN_CORE 0x00001000 |
Definition at line 350 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW6EN_M 0x00003000 |
Definition at line 346 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW6EN_NOTVIS 0x00000000 |
Definition at line 347 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW7EN_CORE 0x00004000 |
Definition at line 356 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW7EN_M 0x0000C000 |
Definition at line 352 of file hw_flash.h.
| #define FLASH_ROMSWMAP_SW7EN_NOTVIS 0x00000000 |
Definition at line 353 of file hw_flash.h.
| #define FLASH_RVP 0x400FE0D4 |
Definition at line 67 of file hw_flash.h.
| #define FLASH_RVP_RV_M 0xFFFFFFFF |
Definition at line 383 of file hw_flash.h.
| #define FLASH_RVP_RV_S 0 |
Definition at line 384 of file hw_flash.h.
| #define FLASH_SSIZE 0x400FDFC4 |
Definition at line 62 of file hw_flash.h.
Referenced by SysCtlSRAMSizeGet().
| #define FLASH_SSIZE_SIZE_12KB 0x0000002F |
Definition at line 288 of file hw_flash.h.
| #define FLASH_SSIZE_SIZE_24KB 0x0000005F |
Definition at line 289 of file hw_flash.h.
| #define FLASH_SSIZE_SIZE_256KB 0x000003FF |
Definition at line 291 of file hw_flash.h.
| #define FLASH_SSIZE_SIZE_32KB 0x0000007F |
Definition at line 290 of file hw_flash.h.
| #define FLASH_SSIZE_SIZE_M 0x0000FFFF |
Definition at line 287 of file hw_flash.h.
| #define FLASH_USERREG0 0x400FE1E0 |
Definition at line 70 of file hw_flash.h.
Referenced by FlashUserGet(), and FlashUserSet().
| #define FLASH_USERREG0_DATA_M 0xFFFFFFFF |
Definition at line 428 of file hw_flash.h.
| #define FLASH_USERREG0_DATA_S 0 |
Definition at line 429 of file hw_flash.h.
| #define FLASH_USERREG1 0x400FE1E4 |
Definition at line 71 of file hw_flash.h.
Referenced by FlashUserGet(), and FlashUserSet().
| #define FLASH_USERREG1_DATA_M 0xFFFFFFFF |
Definition at line 436 of file hw_flash.h.
| #define FLASH_USERREG1_DATA_S 0 |
Definition at line 437 of file hw_flash.h.
| #define FLASH_USERREG2 0x400FE1E8 |
Definition at line 72 of file hw_flash.h.
| #define FLASH_USERREG2_DATA_M 0xFFFFFFFF |
Definition at line 444 of file hw_flash.h.
| #define FLASH_USERREG2_DATA_S 0 |
Definition at line 445 of file hw_flash.h.
| #define FLASH_USERREG3 0x400FE1EC |
Definition at line 73 of file hw_flash.h.
| #define FLASH_USERREG3_DATA_M 0xFFFFFFFF |
Definition at line 452 of file hw_flash.h.
| #define FLASH_USERREG3_DATA_S 0 |
Definition at line 453 of file hw_flash.h.
1.8.9.1
