thread_structures.h File Reference

#include "libstd/defines.h"

Include dependency graph for thread_structures.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	tcb_t
struct	sched_task
struct	sched_task_pool

Macros
#define	SEMAPHORE_DEFAULT_VALUE   0
#define	spinlock_until(blocker)   while (!(*blocker))
#define	sem_init_(sem, initial_value)
#define	sem_guard(sem)   if(!semaphore_blocked(sem))
#define	sem_take(sem)
#define	sem_check(sem)
#define	sem_init(sem)   sem_init_(sem, SEMAPHORE_DEFAULT_VALUE)
#define	sem_signal(sem)   sem_post(sem)
#define	sem_post(sem)
#define	sem_wait(sem)
#define	semaphore_blocked(sem)   (sem <= 0)
#define	thread_blocked(tcb_t)   (tcb_t->sem != NULL)

Typedefs
typedef uint32_t	tick_t
typedef int8_t	semaphore_t
typedef uint8_t	priority_t
typedef int32_t	deadline_t
typedef int32_t	microseconds_t
typedef struct tcb_t	tcb_t
typedef struct sched_task	sched_task
typedef struct sched_task_pool	sched_task_pool

Enumerations
enum	DEADLINE_TYPE { DL_HARD, DL_SOFT }

Macro Definition Documentation

#define sem_check

(

sem

)

Definition at line 48 of file thread_structures.h.

#define sem_guard

(

sem

)

if(!semaphore_blocked(sem))

Guard the following code block to evaluate only in the semaphore may be obtained.

Definition at line 36 of file thread_structures.h.

Referenced by display_adc_data_for_checkout(), hw_daemon(), led_blink_green(), and postpone_suicide().

#define sem_init

(

sem

)

sem_init_(sem, SEMAPHORE_DEFAULT_VALUE)

Initialize a semaphore_t to .

Definition at line 51 of file thread_structures.h.

Referenced by main().

#define sem_init_	(		sem,
			initial_value
	)

Value:

semaphore_t sem;                            \
    sem = initial_value

Initialize to .

Definition at line 30 of file thread_structures.h.

#define sem_post

(

sem

)

Value:

atomic (                                    \
        ++sem;                                  \
       /* TODO: wake thread */                  \
    )

Signal and update all threads watching . If the highest priority thread watching is released by this post, and it is of a higher priority than the currently executing thread, then suspend the current thread. The thread-context switcher will then choose the higher-priority thread to execute.

Definition at line 64 of file thread_structures.h.

Referenced by ADC0Seq2_Handler(), button_debounce_end(), timer_task(), and UART0_Handler().

#define sem_signal

(

sem

)

sem_post(sem)

A convenience alias to to allow comparison of source code to course documents.

Definition at line 56 of file thread_structures.h.

Referenced by TIMER0A_Handler().

#define sem_take

(

sem

)

Value:

atomic (                                    \
        --sem;                                  \
       /* TODO: wake thread */                  \
    )

without the br, to be used when you know you can take the semaphore.

Definition at line 41 of file thread_structures.h.

Referenced by display_adc_data_for_checkout(), hw_daemon(), led_blink_green(), and postpone_suicide().

#define sem_wait

(

sem

)

Value:

while (semaphore_blocked(sem)) {            \
        os_surrender_context();                 \
    }                                           \
    atomic (                                    \
        --sem;                                  \
    )

Stall execution of current thread until is nonblocking. If becomes blocking during this invocation, call for the current executing thread.

Definition at line 73 of file thread_structures.h.

#define semaphore_blocked

(

sem

)

(sem <= 0)

Conditional evaluating to true when a semaphore is blocked by virtue of being non-NULL.

Definition at line 83 of file thread_structures.h.

Referenced by Task1().

#define SEMAPHORE_DEFAULT_VALUE   0

The default initialization value of a semaphore_t.

Definition at line 20 of file thread_structures.h.

#define spinlock_until

(

blocker

)

while (!(*blocker))

Spinlock until is non-zero.

Definition at line 26 of file thread_structures.h.

#define thread_blocked

(

tcb_t

)

(tcb_t->sem != NULL)

Conditional evaluating to true when a thread's tcb_t is blocked by a semaphore.

Definition at line 88 of file thread_structures.h.

Typedef Documentation

typedef int32_t deadline_t

Definition at line 95 of file thread_structures.h.

typedef int32_t microseconds_t

Definition at line 96 of file thread_structures.h.

typedef uint8_t priority_t

OS thread priority levels; 0 is highest.

Definition at line 93 of file thread_structures.h.

typedef struct sched_task sched_task

typedef struct sched_task_pool sched_task_pool

typedef int8_t semaphore_t

Typedef of a semaphore.

Definition at line 23 of file thread_structures.h.

typedef struct tcb_t tcb_t

Thread Control Block definition

typedef uint32_t tick_t

Count of SysTick ticks (each of which is equivalent to a bus cycle). Note that the SysTick can only count down from a 24-bit register.

Definition at line 17 of file thread_structures.h.

Enumeration Type Documentation

enum DEADLINE_TYPE

Enumerator
DL_HARD
DL_SOFT

Definition at line 98 of file thread_structures.h.

             {
    DL_HARD,
    DL_SOFT,
} DEADLINE_TYPE;
