circularbuffer< T, N > Class Template Reference

#include <circularbuffer.hpp>

Inheritance diagram for circularbuffer< T, N >:

Collaboration diagram for circularbuffer< T, N >:

Public Member Functions
	circularbuffer ()
void	increment_ptr (uint32_t *ptr, uint32_t increment, uint32_t wrap_len)
void	add (const T ch)
T	peek ()
T	get (int32_t offset)
Public Member Functions inherited from buffer< T, N >
	buffer ()
	buffer (semaphore *sem)
void	clear ()
void	init ()
void	notify (const T data)
bool	add (const T data)
T	peek ()
T	get (bool &ok)
bool	full ()
bool	empty ()
uint32_t	length ()

Additional Inherited Members
Public Attributes inherited from buffer< T, N >
uint32_t	pos
uint32_t	len
semaphore *	sem
T	buf [N]
uint32_t	error_overflow
uint32_t	error_underflow

Detailed Description

template<typename T, uint32_t N>
class circularbuffer< T, N >

Definition at line 13 of file circularbuffer.hpp.

Constructor & Destructor Documentation

template<typename T, uint32_t N>

circularbuffer< T, N >::circularbuffer ( )

inline

Definition at line 17 of file circularbuffer.hpp.

: buffer<T, N>() { }

Member Function Documentation

template<typename T, uint32_t N>

void circularbuffer< T, N >::add ( const T  ch )

inline

Definition at line 24 of file circularbuffer.hpp.

Referenced by ping::handle_gpio(), and ir::sample().

                         {
        this->buf[this->pos] = ch;
        increment_ptr(&(this->pos), 1, this->len);
    }

Here is the caller graph for this function:

template<typename T, uint32_t N>

T circularbuffer< T, N >::get ( int32_t  offset )

inline

Definition at line 33 of file circularbuffer.hpp.

                          {

        int32_t position_to_get = ((this->pos+offset) % this->len);

        if (position_to_get < 0) {
            return this->buf[position_to_get + this->len];
        }
        return this->buf[position_to_get];
    }

template<typename T, uint32_t N>

void circularbuffer< T, N >::increment_ptr ( uint32_t *  ptr, uint32_t  increment, uint32_t  wrap_len  )

inline

Definition at line 19 of file circularbuffer.hpp.

Referenced by circularbuffer< int16_t, 32 >::add().

                                          {
        *ptr = (*ptr + increment) % wrap_len;
    }

Here is the caller graph for this function:

template<typename T, uint32_t N>

T circularbuffer< T, N >::peek ( )

inline

Definition at line 29 of file circularbuffer.hpp.

             {
        return this->buf(this->pos);
    }

---

The documentation for this class was generated from the following file:

• board-progs/autonomous-racer/common/circularbuffer.hpp
