#include <uartpp.hpp>

Inheritance diagram for uart:

Collaboration diagram for uart:

Public Member Functions
	uart ()

	uart (memory_address_t uart_channel, memory_address_t uart_interrupt, uint32_t uart_baud_rate=115200)

virtual void	start (void)

virtual void	stop (void)

virtual uint32_t	ack (void)

void	send_char (const char)

void	send_string (const char *)

void	send_newline (void)

char	get_char (void)

char *	get_string (const uint32_t length)

void	printf (const char *pcString,...)

void	atomic_printf (const char *pcString,...)

Public Member Functions inherited from interruptable
	interruptable ()

Public Member Functions inherited from critical
uint32_t	StartCritical (void)

void	EndCritical (uint32_t primask)

Public Attributes
char	buffer [UART_DEFAULT_MAX_GET_STRING_LENGTH]

Static Public Attributes
static bool	LAST_WAS_CR

Private Member Functions
void	vprintf (const char *pcString, va_list vaArgP)

Private Attributes
uint32_t	baud_rate

memory_address_t	channel

memory_address_t	interrupt

Additional Inherited Members
Static Public Member Functions inherited from critical
static uint32_t	static_StartCritical (void)

static void	static_EndCritical (uint32_t primask)

Detailed Description

Definition at line 28 of file uartpp.hpp.

Constructor & Destructor Documentation

uart::uart ( )

Definition at line 21 of file uartpp.cpp.

21 {}

uart::uart	(	memory_address_t	uart_channel,
		memory_address_t	uart_interrupt,
		uint32_t	uart_baud_rate = `115200`
	)

Definition at line 24 of file uartpp.cpp.

References baud_rate, channel, interrupt, printf(), and start().

                                     {

     baud_rate = uart_baud_rate;
     channel = uart_channel;
     interrupt = uart_interrupt;

     SysCtlPeripheralEnable(SYSCTL_PERIPH_UART0 +
                            (uart_channel - UART0_BASE) / 0x1000);

     /* todo: parametrize */
     SysCtlPeripheralEnable(SYSCTL_PERIPH_GPIOA);
     GPIOPinConfigure(GPIO_PA0_U0RX);
     GPIOPinConfigure(GPIO_PA1_U0TX);
     GPIOPinTypeUART(GPIO_PORTA_BASE, GPIO_PIN_0 | GPIO_PIN_1);

     UARTConfigSetExpClk(channel, SysCtlClockGet(), baud_rate,
                         (UART_CONFIG_WLEN_8 | UART_CONFIG_STOP_ONE |
                          UART_CONFIG_PAR_NONE));

     start();

     printf("\n\rWelcome to RRTOS v0\n\r");
 }

Here is the call graph for this function:

Member Function Documentation

uint32_t uart::ack ( void )

virtual

Acknowledge interrupt.

Implements interruptable.

Definition at line 386 of file uartpp.cpp.

References channel.

Referenced by get_string(), and UART0_Handler().

                        {

     uint32_t ui32Status;
     ui32Status = UARTIntStatus(channel, true);
     UARTIntClear(channel, ui32Status);
     return ui32Status;
 }

Here is the caller graph for this function:

void uart::atomic_printf	(	const char *	pcString,
			...
	)

Printf atomically over uart.

Definition at line 348 of file uartpp.cpp.

References critical::EndCritical(), critical::StartCritical(), and vprintf().

Referenced by shell::backspace(), can_handler(), shell::execute_command(), shell::print_ps1(), thread_uart_update(), and shell::type().

                                                   {

     va_list vaArgP;
     va_start(vaArgP, pcString);

     uint32_t ui32Status = StartCritical();
     vprintf(pcString, vaArgP);
     EndCritical(ui32Status);

     va_end(vaArgP);
 }

Here is the call graph for this function:

Here is the caller graph for this function:

char uart::get_char ( void )

Receive a char.

Definition at line 381 of file uartpp.cpp.

References channel.

Referenced by get_string(), and UART0_Handler().

                         {

     return UARTCharGet(channel) & 0xFF;
 }

Here is the caller graph for this function:

char * uart::get_string ( const uint32_t length )

Receive a string of LENGTH characters.

Definition at line 394 of file uartpp.cpp.

References ack(), buffer, channel, and get_char().

                                             {

     uint32_t remaining_chars = (uint32_t) length;

     ack();

     while(UARTCharsAvail(channel) && (remaining_chars > 0)) {
         buffer[remaining_chars-- - length] = get_char();
     }
     buffer[length] = 0;

     return buffer;
 }

Here is the call graph for this function:

void uart::printf	(	const char *	pcString,
			...
	)

Printf over uart.

Definition at line 360 of file uartpp.cpp.

References vprintf().

Referenced by can_handler(), can_transmitter(), ping_handler(), timer_updater(), and uart().

                                            {

     va_list vaArgP;
     va_start(vaArgP, pcString);

     vprintf(pcString, vaArgP);

     va_end(vaArgP);
 }

Here is the call graph for this function:

Here is the caller graph for this function:

void uart::send_char ( const char ch )

Send a char.

Definition at line 371 of file uartpp.cpp.

References channel.

Referenced by send_string().

                                   {

     UARTCharPut(channel, ch);
 }

Here is the caller graph for this function:

void uart::send_newline ( void )

Send a newline and carriage return;

Definition at line 376 of file uartpp.cpp.

References send_string().

                             {

     send_string("\r\n");
 }

Here is the call graph for this function:

void uart::send_string ( const char * str )

Send a string.

Definition at line 49 of file uartpp.cpp.

References channel, send_char(), and ustrlen().

Referenced by send_newline().

                                       {

     uint32_t len = ustrlen(str);
     char* ptr = (char*)str;

     while(len--) {
         while(!UARTSpaceAvail(channel)) {}
         send_char(*(ptr++));
     }
 }

Here is the call graph for this function:

Here is the caller graph for this function:

void uart::start ( void )

virtual

Enable the uart.

Implements interruptable.

Definition at line 408 of file uartpp.cpp.

References channel, and interrupt.

Referenced by uart().

                      {

     IntEnable(interrupt);
     UARTIntEnable(channel, UART_INT_RX | UART_INT_RT);
 }

Here is the caller graph for this function:

void uart::stop ( void )

virtual

Disable the uart.

Implements interruptable.

Definition at line 414 of file uartpp.cpp.

References channel, and interrupt.

                     {

     IntDisable(interrupt);
     UARTIntDisable(channel, UART_INT_RX | UART_INT_RT);
 }

void uart::vprintf	(	const char *	pcString,
		va_list	vaArgP
	)

private

Definition at line 122 of file uartpp.cpp.

References channel, g_pcHex, and UARTwrite().

Referenced by atomic_printf(), and printf().

                                                        {
     uint32_t ui32Idx, ui32Value, ui32Pos, ui32Count, ui32Base, ui32Neg;
     char *pcStr, pcBuf[16], cFill;

     // Loop while there are more characters in the string.
     while(*pcString)
     {
         // Find the first non-% character, or the end of the string.
         for(ui32Idx = 0;
             (pcString[ui32Idx] != '%') && (pcString[ui32Idx] != '\0');
             ui32Idx++) {}

         // Write this portion of the string.
         UARTwrite(channel, pcString, ui32Idx);

         // Skip the portion of the string that was written.
         pcString += ui32Idx;

         // See if the next character is a %.
         if(*pcString == '%') {

             // Skip the %.
             pcString++;

             // Set the digit count to zero, and the fill character to space
             // (in other words, to the defaults).
             ui32Count = 0;
             cFill = ' ';

             // It may be necessary to get back here to process more characters.
             // Goto's aren't pretty, but effective.  I feel extremely dirty for
             // using not one but two of the beasts.
 again:

             // Determine how to handle the next character.
             switch(*pcString++) {

                 // Handle the digit characters.
                 case '0':
                 case '1':
                 case '2':
                 case '3':
                 case '4':
                 case '5':
                 case '6':
                 case '7':
                 case '8':
                 case '9':
                     // If this is a zero, and it is the first digit, then the
                     // fill character is a zero instead of a space.
                     if((pcString[-1] == '0') && (ui32Count == 0)) {
                         cFill = '0';
                     }

                     // Update the digit count.
                     ui32Count *= 10;
                     ui32Count += pcString[-1] - '0';

                     // Get the next character.
                     goto again;

                 // Handle the %c command.
                 case 'c':
                     // Get the value from the varargs.
                     ui32Value = va_arg(vaArgP, uint32_t);

                     // Print out the character.
                     UARTwrite(channel, (char *)&ui32Value, 1);

                     // This command has been handled.
                     break;

                 // Handle the %d and %i commands.
                 case 'd':
                 case 'i':
                     // Get the value from the varargs.
                     ui32Value = va_arg(vaArgP, uint32_t);

                     // Reset the buffer position.
                     ui32Pos = 0;

                     // If the value is negative, make it positive and indicate
                     // that a minus sign is needed.
                     if((int32_t)ui32Value < 0) {

                         // Make the value positive.
                         ui32Value = -(int32_t)ui32Value;
                         // Indicate that the value is negative.
                         ui32Neg = 1;
                     } else {
                         // Indicate that the value is positive so that a minus
                         // sign isn't inserted.
                         ui32Neg = 0;
                     }

                     // Set the base to 10.
                     ui32Base = 10;

                     // Convert the value to ASCII.
                     goto convert;

                 // Handle the %s command.
                 case 's':
                     // Get the string pointer from the varargs.
                     pcStr = va_arg(vaArgP, char *);

                     // Determine the length of the string.
                     for(ui32Idx = 0; pcStr[ui32Idx] != '\0'; ui32Idx++) {}

                     // Write the string.
                     UARTwrite(channel, pcStr, ui32Idx);

                     // Write any required padding spaces
                     if(ui32Count > ui32Idx) {
                         ui32Count -= ui32Idx;
                         while(ui32Count--) {
                             UARTwrite(channel, " ", 1);
                         }
                     }
                     break;

                 // Handle the %u command.
                 case 'u':
                     // Get the value from the varargs.
                     ui32Value = va_arg(vaArgP, uint32_t);

                     // Reset the buffer position.
                     ui32Pos = 0;

                     // Set the base to 10.
                     ui32Base = 10;

                     // Indicate that the value is positive so that a minus sign
                     // isn't inserted.
                     ui32Neg = 0;

                     // Convert the value to ASCII.
                     goto convert;

                 // Handle the %x and %X commands.  Note that they are treated
                 // identically; in other words, %X will use lower case letters
                 // for a-f instead of the upper case letters it should use.  We
                 // also alias %p to %x.
                 case 'x':
                 case 'X':
                 case 'p':
                     // Get the value from the varargs.
                     ui32Value = va_arg(vaArgP, uint32_t);

                     // Reset the buffer position.
                     ui32Pos = 0;

                     // Set the base to 16.
                     ui32Base = 16;

                     // Indicate that the value is positive so that a minus sign
                     // isn't inserted.
                     ui32Neg = 0;

                     // Determine the number of digits in the string version of
                     // the value.
 convert:
                     for(ui32Idx = 1;
                         (((ui32Idx * ui32Base) <= ui32Value) &&
                          (((ui32Idx * ui32Base) / ui32Base) == ui32Idx));
                         ui32Idx *= ui32Base, ui32Count--) {}

                     // If the value is negative, reduce the count of padding
                     // characters needed.
                     if(ui32Neg) {
                         ui32Count--;
                     }

                     // If the value is negative and the value is padded with
                     // zeros, then place the minus sign before the padding.
                     if(ui32Neg && (cFill == '0')) {
                         // Place the minus sign in the output buffer.
                         pcBuf[ui32Pos++] = '-';

                         // The minus sign has been placed, so turn off the
                         // negative flag.
                         ui32Neg = 0;
                     }

                     // Provide additional padding at the beginning of the
                     // string conversion if needed.
                     if((ui32Count > 1) && (ui32Count < 16)) {
                         for(ui32Count--; ui32Count; ui32Count--) {
                             pcBuf[ui32Pos++] = cFill;
                         }
                     }

                     // If the value is negative, then place the minus sign
                     // before the number.
                     if(ui32Neg) {
                         // Place the minus sign in the output buffer.
                         pcBuf[ui32Pos++] = '-';
                     }

                     // Convert the value into a string.
                     for(; ui32Idx; ui32Idx /= ui32Base) {
                         pcBuf[ui32Pos++] =
                             g_pcHex[(ui32Value / ui32Idx) % ui32Base];
                     }

                     // Write the string.
                     UARTwrite(channel, pcBuf, ui32Pos);

                     break;

                 // Handle the %% command.
                 case '%':
                     // Simply write a single %.
                     UARTwrite(channel, pcString - 1, 1);
                     break;

                 // Handle all other commands.
                 default:
                      // Indicate an error.
                     UARTwrite(channel, "ERROR", 5);
                      break;
             }
         }
     }
 }
