clock.h File Reference

#include "libmath/geometry/shape.h"
#include "timekit.h"

Include dependency graph for clock.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	clockhand
struct	clockface

Macros
#define	CH_HOURS   1
#define	CH_MINUTES   2
#define	CH_SECONDS   3
#define	CH_MS   4
#define	CH_MAX_HOURS   12
#define	CH_MAX_MINUTES   60
#define	CH_MAX_SECONDS   60
#define	CH_MAX_MS   1000
#define	CH_MAX_DEGREES   360
#define	CH_ANGLE_OFFSET   90.0
#define	PI_PI   3.142159

Typedefs
typedef struct clockhand	clockhand
typedef struct clockface	clockface

Functions
clockhand *	CHCreateClockHand (point *center, ushort radius, uchar type)
void	CHCalculateAngle (clockhand *ch, clocktime *tm)
shape *	CHToShape (clockhand *ch)
void	CHDestroyClockHand (clockhand *ch)
void	CHDestroyClockHandShape (clockhand *ch)
clockface *	CFCreateClockFace (ushort numHands, clockhand **chs, clocktime *th)
void	CFDestroyClockFace (clockface *cf)
void	CFUpdateTime (clockface *cf)
shape **	CFToShapes (clockface *cf)
void	CFDestroyShapes (clockface *cf)

Macro Definition Documentation

#define CH_ANGLE_OFFSET   90.0

Definition at line 27 of file clock.h.

Referenced by CHToShape().

#define CH_HOURS   1

Definition at line 16 of file clock.h.

Referenced by CHCalculateAngle(), and demonstrateClock().

#define CH_MAX_DEGREES   360

Definition at line 26 of file clock.h.

#define CH_MAX_HOURS   12

Definition at line 21 of file clock.h.

#define CH_MAX_MINUTES   60

Definition at line 22 of file clock.h.

#define CH_MAX_MS   1000

Definition at line 24 of file clock.h.

#define CH_MAX_SECONDS   60

Definition at line 23 of file clock.h.

#define CH_MINUTES   2

Definition at line 17 of file clock.h.

Referenced by CHCalculateAngle(), and demonstrateClock().

#define CH_MS   4

Definition at line 19 of file clock.h.

Referenced by CHCalculateAngle(), and demonstrateClock().

#define CH_SECONDS   3

Definition at line 18 of file clock.h.

Referenced by CHCalculateAngle(), and demonstrateClock().

#define PI_PI   3.142159

Definition at line 29 of file clock.h.

Referenced by CHToShape().

Typedef Documentation

typedef struct clockface clockface

typedef struct clockhand clockhand

Function Documentation

clockface* CFCreateClockFace	(	ushort	numHands,
		clockhand **	chs,
		clocktime *	th
	)

Definition at line 91 of file clock.c.

References clockface::hands, clockface::numHands, and clockface::timehandle.

Referenced by demonstrateClock().

                                                                              {

  ushort i;
  clockface* cf = (clockface*) calloc(1, sizeof(clockface));

  /* Moved to CFToShapes */
  /* cf->shapeBuffer = (shape**)malloc(numHands * sizeof(shape*)); */
  cf->numHands = numHands;

  /* Shallow copy of clockhands */
  cf->hands = (clockhand**) calloc(numHands, sizeof(clockhand*));
  for(i=0; i < numHands; ++i) {
      cf->hands[i] = chs[i];
  }

  /* Don't deep copy timehandle, we need it for the interrupt */
  cf->timehandle = th;

  return cf;
}

Here is the caller graph for this function:

void CFDestroyClockFace

(

clockface *

cf

)

Definition at line 112 of file clock.c.

References clockface::hands.

Referenced by demonstrateClock().

                                       {
  free(cf->hands);
  free(cf);
}

Here is the caller graph for this function:

void CFDestroyShapes

(

clockface *

cf

)

Definition at line 146 of file clock.c.

References CHDestroyClockHandShape(), clockface::hands, clockface::numHands, and clockface::shapeBuffer.

Referenced by demonstrateClock().

                                    {
  ushort i;
  for(i=0; i<cf->numHands; ++i) {
    /* free(cf->shapeBuffer[i]); */
    CHDestroyClockHandShape(cf->hands[i]);
  }
  free(cf->shapeBuffer);
}

Here is the call graph for this function:

Here is the caller graph for this function:

shape** CFToShapes

(

clockface *

cf

)

Definition at line 135 of file clock.c.

References CHToShape(), clockface::hands, clockface::numHands, and clockface::shapeBuffer.

Referenced by demonstrateClock().

                                  {
  ushort i;

  cf->shapeBuffer = (shape**)malloc(cf->numHands * sizeof(shape*));

  for(i=0; i<cf->numHands; ++i) {
    cf->shapeBuffer[i] = CHToShape(cf->hands[i]);
  }
  return cf->shapeBuffer;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void CFUpdateTime

(

clockface *

cf

)

Definition at line 128 of file clock.c.

References CHCalculateAngle(), clockface::hands, clockface::numHands, and clockface::timehandle.

Referenced by demonstrateClock().

                                 {
  ushort i;
  for(i=0; i<cf->numHands; ++i) {
    CHCalculateAngle(cf->hands[i], cf->timehandle);
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void CHCalculateAngle	(	clockhand *	ch,
		clocktime *	tm
	)

Definition at line 46 of file clock.c.

References clockhand::angle, CH_HOURS, CH_MINUTES, CH_MS, CH_SECONDS, clocktime::hours, clocktime::minutes, clocktime::ms, clocktime::seconds, and clockhand::type.

Referenced by CFUpdateTime().

                                                    {
  ushort tmpHours;

  switch(ch->type) {
  case CH_HOURS:
    tmpHours = tm->hours;
    while(tmpHours > 12) {
      tmpHours -= 12;
    }
    ch->angle = (short)(30*tmpHours + (tm->minutes)/2.0);
    break;
  case CH_MINUTES:
    ch->angle = (short)(6.0*tm->minutes + tm->seconds/10.0);
    break;
  case CH_SECONDS:
    ch->angle = 6*tm->seconds + 3.0/500*tm->ms;
    break;
  case CH_MS:
    ch->angle = (short)((9/25.0)*(tm->ms));
    break;
  }

  /* printf("--- ANGLE FOR %i: %i --- %i\n", ch->type, ch->angle, CH_SECONDS); */
}

Here is the caller graph for this function:

clockhand* CHCreateClockHand	(	point *	center,
		ushort	radius,
		uchar	type
	)

Definition at line 32 of file clock.c.

References clockhand::angle, clockhand::center, clockhand::pointOnCircumference, clockhand::radius, shape_duplicate_point(), and clockhand::type.

Referenced by demonstrateClock().

                                                                       {
  clockhand* ch = (clockhand*) calloc(1, sizeof(clockhand));

  ch->radius = radius;
  ch->center = shape_duplicate_point(center);
  ch->type = type;

  ch->angle = 0;

  ch->pointOnCircumference = shape_duplicate_point(center);

  return ch;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void CHDestroyClockHand

(

clockhand *

ch

)

Definition at line 71 of file clock.c.

References clockhand::center, and clockhand::pointOnCircumference.

Referenced by demonstrateClock().

                                       {

  /* SHDestroyShape(ch->shapeBuffer); */
  /* free(ch->shapeBuffer); */
  free(ch->pointOnCircumference);
  free(ch->center);
  free(ch);
}

Here is the caller graph for this function:

void CHDestroyClockHandShape

(

clockhand *

ch

)

Definition at line 80 of file clock.c.

References shape::points, and clockhand::shapeBuffer.

Referenced by CFDestroyShapes().

                                            {

  /* point* p; */
  /* p = SHCreatePoint(p->x, p->y, p->shade); */
  /* SHDestroyShape(ch->shapeBuffer); */
  /* ch->center = p; */

  free(ch->shapeBuffer->points);
  free(ch->shapeBuffer);
}

Here is the caller graph for this function:

shape* CHToShape

(

clockhand *

ch

)

Definition at line 15 of file clock.c.

References clockhand::angle, clockhand::center, CH_ANGLE_OFFSET, PI_PI, clockhand::pointOnCircumference, clockhand::radius, shape_create(), clockhand::shapeBuffer, point::x, and point::y.

Referenced by CFToShapes().

                                {
  float x, y;

  x = cosf((ch->angle - CH_ANGLE_OFFSET) * PI_PI / 180) * ch->radius;
  y = sinf((ch->angle - CH_ANGLE_OFFSET) * PI_PI / 180) * ch->radius;

  /* avoid underflow (subtracting too much from an unsigned number) */
  if(-x > ch->center->x) {x = -ch->center->x;}
  if(-y > ch->center->y) {y = -ch->center->y;}

  ch->pointOnCircumference->x = ch->center->x+x;
  ch->pointOnCircumference->y = ch->center->y+y;

  ch->shapeBuffer = shape_create(2, ch->center, ch->pointOnCircumference);
  return ch->shapeBuffer;
}

Here is the call graph for this function:

Here is the caller graph for this function:
