Go to the source code of this file.
Macros | |
| #define | GPIO_O_DATA 0x00000000 |
| #define | GPIO_O_DIR 0x00000400 |
| #define | GPIO_O_IS 0x00000404 |
| #define | GPIO_O_IBE 0x00000408 |
| #define | GPIO_O_IEV 0x0000040C |
| #define | GPIO_O_IM 0x00000410 |
| #define | GPIO_O_RIS 0x00000414 |
| #define | GPIO_O_MIS 0x00000418 |
| #define | GPIO_O_ICR 0x0000041C |
| #define | GPIO_O_AFSEL 0x00000420 |
| #define | GPIO_O_DR2R 0x00000500 |
| #define | GPIO_O_DR4R 0x00000504 |
| #define | GPIO_O_DR8R 0x00000508 |
| #define | GPIO_O_ODR 0x0000050C |
| #define | GPIO_O_PUR 0x00000510 |
| #define | GPIO_O_PDR 0x00000514 |
| #define | GPIO_O_SLR 0x00000518 |
| #define | GPIO_O_DEN 0x0000051C |
| #define | GPIO_O_LOCK 0x00000520 |
| #define | GPIO_O_CR 0x00000524 |
| #define | GPIO_O_AMSEL 0x00000528 |
| #define | GPIO_O_PCTL 0x0000052C |
| #define | GPIO_O_ADCCTL 0x00000530 |
| #define | GPIO_O_DMACTL 0x00000534 |
| #define | GPIO_O_SI 0x00000538 |
| #define | GPIO_O_DR12R 0x0000053C |
| #define | GPIO_O_WAKEPEN 0x00000540 |
| #define | GPIO_O_WAKELVL 0x00000544 |
| #define | GPIO_O_WAKESTAT 0x00000548 |
| #define | GPIO_O_PP 0x00000FC0 |
| #define | GPIO_O_PC 0x00000FC4 |
| #define | GPIO_IM_DMAIME 0x00000100 |
| #define | GPIO_IM_GPIO_M 0x000000FF |
| #define | GPIO_IM_GPIO_S 0 |
| #define | GPIO_RIS_DMARIS 0x00000100 |
| #define | GPIO_RIS_GPIO_M 0x000000FF |
| #define | GPIO_RIS_GPIO_S 0 |
| #define | GPIO_MIS_DMAMIS 0x00000100 |
| #define | GPIO_MIS_GPIO_M 0x000000FF |
| #define | GPIO_MIS_GPIO_S 0 |
| #define | GPIO_ICR_DMAIC 0x00000100 |
| #define | GPIO_ICR_GPIO_M 0x000000FF |
| #define | GPIO_ICR_GPIO_S 0 |
| #define | GPIO_LOCK_M 0xFFFFFFFF |
| #define | GPIO_LOCK_UNLOCKED 0x00000000 |
| #define | GPIO_LOCK_LOCKED 0x00000001 |
| #define | GPIO_LOCK_KEY 0x4C4F434B |
| #define | GPIO_SI_SUM 0x00000001 |
| #define | GPIO_DR12R_DRV12_M 0x000000FF |
| #define | GPIO_DR12R_DRV12_12MA 0x00000001 |
| #define | GPIO_WAKEPEN_WAKEP4 0x00000010 |
| #define | GPIO_WAKELVL_WAKELVL4 0x00000010 |
| #define | GPIO_WAKESTAT_STAT4 0x00000010 |
| #define | GPIO_PP_EDE 0x00000001 |
| #define | GPIO_PC_EDM7_M 0x0000C000 |
| #define | GPIO_PC_EDM6_M 0x00003000 |
| #define | GPIO_PC_EDM5_M 0x00000C00 |
| #define | GPIO_PC_EDM4_M 0x00000300 |
| #define | GPIO_PC_EDM3_M 0x000000C0 |
| #define | GPIO_PC_EDM2_M 0x00000030 |
| #define | GPIO_PC_EDM1_M 0x0000000C |
| #define | GPIO_PC_EDM0_M 0x00000003 |
| #define | GPIO_PC_EDM0_DISABLE 0x00000000 |
| #define | GPIO_PC_EDM0_6MA 0x00000001 |
| #define | GPIO_PC_EDM0_PLUS2MA 0x00000003 |
| #define | GPIO_PC_EDM7_S 14 |
| #define | GPIO_PC_EDM6_S 12 |
| #define | GPIO_PC_EDM5_S 10 |
| #define | GPIO_PC_EDM4_S 8 |
| #define | GPIO_PC_EDM3_S 6 |
| #define | GPIO_PC_EDM2_S 4 |
| #define | GPIO_PC_EDM1_S 2 |
| #define GPIO_LOCK_KEY 0x4C4F434B |
Definition at line 129 of file hw_gpio.h.
Referenced by button_init().
| #define GPIO_O_ADCCTL 0x00000530 |
Definition at line 70 of file hw_gpio.h.
Referenced by GPIOADCTriggerDisable(), and GPIOADCTriggerEnable().
| #define GPIO_O_AFSEL 0x00000420 |
Definition at line 57 of file hw_gpio.h.
Referenced by GPIODirModeGet(), and GPIODirModeSet().
| #define GPIO_O_AMSEL 0x00000528 |
Definition at line 68 of file hw_gpio.h.
Referenced by GPIOPadConfigSet().
| #define GPIO_O_CR 0x00000524 |
Definition at line 67 of file hw_gpio.h.
Referenced by button_init().
| #define GPIO_O_DATA 0x00000000 |
Definition at line 48 of file hw_gpio.h.
Referenced by GPIOPinRead(), and GPIOPinWrite().
| #define GPIO_O_DEN 0x0000051C |
Definition at line 65 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_DIR 0x00000400 |
Definition at line 49 of file hw_gpio.h.
Referenced by GPIODirModeGet(), and GPIODirModeSet().
| #define GPIO_O_DMACTL 0x00000534 |
Definition at line 71 of file hw_gpio.h.
Referenced by GPIODMATriggerDisable(), and GPIODMATriggerEnable().
| #define GPIO_O_DR12R 0x0000053C |
Definition at line 73 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_DR2R 0x00000500 |
Definition at line 58 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_DR4R 0x00000504 |
Definition at line 59 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_DR8R 0x00000508 |
Definition at line 60 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_IBE 0x00000408 |
Definition at line 51 of file hw_gpio.h.
Referenced by GPIOIntTypeGet(), and GPIOIntTypeSet().
| #define GPIO_O_ICR 0x0000041C |
Definition at line 56 of file hw_gpio.h.
Referenced by GPIOIntClear().
| #define GPIO_O_IEV 0x0000040C |
Definition at line 52 of file hw_gpio.h.
Referenced by GPIOIntTypeGet(), and GPIOIntTypeSet().
| #define GPIO_O_IM 0x00000410 |
Definition at line 53 of file hw_gpio.h.
Referenced by GPIOIntDisable(), and GPIOIntEnable().
| #define GPIO_O_IS 0x00000404 |
Definition at line 50 of file hw_gpio.h.
Referenced by GPIOIntTypeGet(), and GPIOIntTypeSet().
| #define GPIO_O_LOCK 0x00000520 |
Definition at line 66 of file hw_gpio.h.
Referenced by button_init().
| #define GPIO_O_MIS 0x00000418 |
Definition at line 55 of file hw_gpio.h.
Referenced by GPIOIntStatus().
| #define GPIO_O_ODR 0x0000050C |
Definition at line 61 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_PC 0x00000FC4 |
Definition at line 78 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_PCTL 0x0000052C |
Definition at line 69 of file hw_gpio.h.
Referenced by GPIOPinConfigure().
| #define GPIO_O_PDR 0x00000514 |
Definition at line 63 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_PUR 0x00000510 |
Definition at line 62 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_RIS 0x00000414 |
Definition at line 54 of file hw_gpio.h.
Referenced by GPIOIntStatus().
| #define GPIO_O_SI 0x00000538 |
Definition at line 72 of file hw_gpio.h.
Referenced by GPIOIntTypeGet(), and GPIOIntTypeSet().
| #define GPIO_O_SLR 0x00000518 |
Definition at line 64 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_WAKELVL 0x00000544 |
Definition at line 75 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_WAKEPEN 0x00000540 |
Definition at line 74 of file hw_gpio.h.
Referenced by GPIOPadConfigGet(), and GPIOPadConfigSet().
| #define GPIO_O_WAKESTAT 0x00000548 |
Definition at line 76 of file hw_gpio.h.
Referenced by GPIOPinWakeStatus().
