Go to the source code of this file.
Macros | |
| #define | TIMER_CFG_ONE_SHOT 0x00000021 |
| #define | TIMER_CFG_ONE_SHOT_UP 0x00000031 |
| #define | TIMER_CFG_PERIODIC 0x00000022 |
| #define | TIMER_CFG_PERIODIC_UP 0x00000032 |
| #define | TIMER_CFG_RTC 0x01000000 |
| #define | TIMER_CFG_SPLIT_PAIR 0x04000000 |
| #define | TIMER_CFG_A_ONE_SHOT 0x00000021 |
| #define | TIMER_CFG_A_ONE_SHOT_UP 0x00000031 |
| #define | TIMER_CFG_A_PERIODIC 0x00000022 |
| #define | TIMER_CFG_A_PERIODIC_UP 0x00000032 |
| #define | TIMER_CFG_A_CAP_COUNT 0x00000003 |
| #define | TIMER_CFG_A_CAP_COUNT_UP 0x00000013 |
| #define | TIMER_CFG_A_CAP_TIME 0x00000007 |
| #define | TIMER_CFG_A_CAP_TIME_UP 0x00000017 |
| #define | TIMER_CFG_A_PWM 0x0000000A |
| #define | TIMER_CFG_B_ONE_SHOT 0x00002100 |
| #define | TIMER_CFG_B_ONE_SHOT_UP 0x00003100 |
| #define | TIMER_CFG_B_PERIODIC 0x00002200 |
| #define | TIMER_CFG_B_PERIODIC_UP 0x00003200 |
| #define | TIMER_CFG_B_CAP_COUNT 0x00000300 |
| #define | TIMER_CFG_B_CAP_COUNT_UP 0x00001300 |
| #define | TIMER_CFG_B_CAP_TIME 0x00000700 |
| #define | TIMER_CFG_B_CAP_TIME_UP 0x00001700 |
| #define | TIMER_CFG_B_PWM 0x00000A00 |
| #define | TIMER_CFG_A_ACT_TOINTD 0x00010000 |
| #define | TIMER_CFG_A_ACT_NONE 0x00000000 |
| #define | TIMER_CFG_A_ACT_TOGGLE 0x00020000 |
| #define | TIMER_CFG_A_ACT_CLRTO 0x00040000 |
| #define | TIMER_CFG_A_ACT_SETTO 0x00060000 |
| #define | TIMER_CFG_A_ACT_SETTOGTO 0x00080000 |
| #define | TIMER_CFG_A_ACT_CLRTOGTO 0x000A0000 |
| #define | TIMER_CFG_A_ACT_SETCLRTO 0x000C0000 |
| #define | TIMER_CFG_A_ACT_CLRSETTO 0x000E0000 |
| #define | TIMER_CFG_B_ACT_TOINTD 0x00100000 |
| #define | TIMER_CFG_B_ACT_NONE 0x00000000 |
| #define | TIMER_CFG_B_ACT_TOGGLE 0x00200000 |
| #define | TIMER_CFG_B_ACT_CLRTO 0x00400000 |
| #define | TIMER_CFG_B_ACT_SETTO 0x00600000 |
| #define | TIMER_CFG_B_ACT_SETTOGTO 0x00800000 |
| #define | TIMER_CFG_B_ACT_CLRTOGTO 0x00A00000 |
| #define | TIMER_CFG_B_ACT_SETCLRTO 0x00C00000 |
| #define | TIMER_CFG_B_ACT_CLRSETTO 0x0000E000 |
| #define | TIMER_TIMB_DMA 0x00002000 |
| #define | TIMER_TIMB_MATCH 0x00000800 |
| #define | TIMER_CAPB_EVENT 0x00000400 |
| #define | TIMER_CAPB_MATCH 0x00000200 |
| #define | TIMER_TIMB_TIMEOUT 0x00000100 |
| #define | TIMER_TIMA_DMA 0x00000020 |
| #define | TIMER_TIMA_MATCH 0x00000010 |
| #define | TIMER_RTC_MATCH 0x00000008 |
| #define | TIMER_CAPA_EVENT 0x00000004 |
| #define | TIMER_CAPA_MATCH 0x00000002 |
| #define | TIMER_TIMA_TIMEOUT 0x00000001 |
| #define | TIMER_EVENT_POS_EDGE 0x00000000 |
| #define | TIMER_EVENT_NEG_EDGE 0x00000404 |
| #define | TIMER_EVENT_BOTH_EDGES 0x00000C0C |
| #define | TIMER_A 0x000000ff |
| #define | TIMER_B 0x0000ff00 |
| #define | TIMER_BOTH 0x0000ffff |
| #define | TIMER_0A_SYNC 0x00000001 |
| #define | TIMER_0B_SYNC 0x00000002 |
| #define | TIMER_1A_SYNC 0x00000004 |
| #define | TIMER_1B_SYNC 0x00000008 |
| #define | TIMER_2A_SYNC 0x00000010 |
| #define | TIMER_2B_SYNC 0x00000020 |
| #define | TIMER_3A_SYNC 0x00000040 |
| #define | TIMER_3B_SYNC 0x00000080 |
| #define | TIMER_4A_SYNC 0x00000100 |
| #define | TIMER_4B_SYNC 0x00000200 |
| #define | TIMER_5A_SYNC 0x00000400 |
| #define | TIMER_5B_SYNC 0x00000800 |
| #define | WTIMER_0A_SYNC 0x00001000 |
| #define | WTIMER_0B_SYNC 0x00002000 |
| #define | WTIMER_1A_SYNC 0x00004000 |
| #define | WTIMER_1B_SYNC 0x00008000 |
| #define | WTIMER_2A_SYNC 0x00010000 |
| #define | WTIMER_2B_SYNC 0x00020000 |
| #define | WTIMER_3A_SYNC 0x00040000 |
| #define | WTIMER_3B_SYNC 0x00080000 |
| #define | WTIMER_4A_SYNC 0x00100000 |
| #define | WTIMER_4B_SYNC 0x00200000 |
| #define | WTIMER_5A_SYNC 0x00400000 |
| #define | WTIMER_5B_SYNC 0x00800000 |
| #define | TIMER_CLOCK_SYSTEM 0x00000000 |
| #define | TIMER_CLOCK_PIOSC 0x00000001 |
| #define | TIMER_DMA_MODEMATCH_B 0x00000800 |
| #define | TIMER_DMA_CAPEVENT_B 0x00000400 |
| #define | TIMER_DMA_CAPMATCH_B 0x00000200 |
| #define | TIMER_DMA_TIMEOUT_B 0x00000100 |
| #define | TIMER_DMA_MODEMATCH_A 0x00000010 |
| #define | TIMER_DMA_RTC_A 0x00000008 |
| #define | TIMER_DMA_CAPEVENT_A 0x00000004 |
| #define | TIMER_DMA_CAPMATCH_A 0x00000002 |
| #define | TIMER_DMA_TIMEOUT_A 0x00000001 |
| #define | TIMER_ADC_MODEMATCH_B 0x00000800 |
| #define | TIMER_ADC_CAPEVENT_B 0x00000400 |
| #define | TIMER_ADC_CAPMATCH_B 0x00000200 |
| #define | TIMER_ADC_TIMEOUT_B 0x00000100 |
| #define | TIMER_ADC_MODEMATCH_A 0x00000010 |
| #define | TIMER_ADC_RTC_A 0x00000008 |
| #define | TIMER_ADC_CAPEVENT_A 0x00000004 |
| #define | TIMER_ADC_CAPMATCH_A 0x00000002 |
| #define | TIMER_ADC_TIMEOUT_A 0x00000001 |
| #define | TIMER_UP_LOAD_IMMEDIATE 0x00000000 |
| #define | TIMER_UP_LOAD_TIMEOUT 0x00000100 |
| #define | TIMER_UP_MATCH_IMMEDIATE 0x00000000 |
| #define | TIMER_UP_MATCH_TIMEOUT 0x00000400 |
Functions | |
| void | TimerEnable (uint32_t ui32Base, uint32_t ui32Timer) |
| void | TimerDisable (uint32_t ui32Base, uint32_t ui32Timer) |
| void | TimerConfigure (uint32_t ui32Base, uint32_t ui32Config) |
| void | TimerControlLevel (uint32_t ui32Base, uint32_t ui32Timer, bool bInvert) |
| void | TimerControlTrigger (uint32_t ui32Base, uint32_t ui32Timer, bool bEnable) |
| void | TimerControlEvent (uint32_t ui32Base, uint32_t ui32Timer, uint32_t ui32Event) |
| void | TimerControlStall (uint32_t ui32Base, uint32_t ui32Timer, bool bStall) |
| void | TimerControlWaitOnTrigger (uint32_t ui32Base, uint32_t ui32Timer, bool bWait) |
| void | TimerRTCEnable (uint32_t ui32Base) |
| void | TimerRTCDisable (uint32_t ui32Base) |
| void | TimerPrescaleSet (uint32_t ui32Base, uint32_t ui32Timer, uint32_t ui32Value) |
| uint32_t | TimerPrescaleGet (uint32_t ui32Base, uint32_t ui32Timer) |
| void | TimerPrescaleMatchSet (uint32_t ui32Base, uint32_t ui32Timer, uint32_t ui32Value) |
| uint32_t | TimerPrescaleMatchGet (uint32_t ui32Base, uint32_t ui32Timer) |
| void | TimerLoadSet (uint32_t ui32Base, uint32_t ui32Timer, uint32_t ui32Value) |
| uint32_t | TimerLoadGet (uint32_t ui32Base, uint32_t ui32Timer) |
| void | TimerLoadSet64 (uint32_t ui32Base, uint64_t ui64Value) |
| uint64_t | TimerLoadGet64 (uint32_t ui32Base) |
| uint32_t | TimerValueGet (uint32_t ui32Base, uint32_t ui32Timer) |
| uint64_t | TimerValueGet64 (uint32_t ui32Base) |
| void | TimerMatchSet (uint32_t ui32Base, uint32_t ui32Timer, uint32_t ui32Value) |
| uint32_t | TimerMatchGet (uint32_t ui32Base, uint32_t ui32Timer) |
| void | TimerMatchSet64 (uint32_t ui32Base, uint64_t ui64Value) |
| uint64_t | TimerMatchGet64 (uint32_t ui32Base) |
| void | TimerIntRegister (uint32_t ui32Base, uint32_t ui32Timer, void(*pfnHandler)(void)) |
| void | TimerIntUnregister (uint32_t ui32Base, uint32_t ui32Timer) |
| void | TimerIntEnable (uint32_t ui32Base, uint32_t ui32IntFlags) |
| void | TimerIntDisable (uint32_t ui32Base, uint32_t ui32IntFlags) |
| uint32_t | TimerIntStatus (uint32_t ui32Base, bool bMasked) |
| void | TimerIntClear (uint32_t ui32Base, uint32_t ui32IntFlags) |
| void | TimerSynchronize (uint32_t ui32Base, uint32_t ui32Timers) |
| uint32_t | TimerClockSourceGet (uint32_t ui32Base) |
| void | TimerClockSourceSet (uint32_t ui32Base, uint32_t ui32Source) |
| uint32_t | TimerADCEventGet (uint32_t ui32Base) |
| void | TimerADCEventSet (uint32_t ui32Base, uint32_t ui32ADCEvent) |
| uint32_t | TimerDMAEventGet (uint32_t ui32Base) |
| void | TimerDMAEventSet (uint32_t ui32Base, uint32_t ui32DMAEvent) |
| void | TimerUpdateMode (uint32_t ui32Base, uint32_t ui32Timer, uint32_t ui32Config) |
| #define TIMER_A 0x000000ff |
Definition at line 152 of file timer.h.
Referenced by adc_interrupt_init(), main(), timer_add_interrupt(), TimerControlEvent(), TimerControlLevel(), TimerControlStall(), TimerControlTrigger(), TimerControlWaitOnTrigger(), TimerDisable(), TimerEnable(), TimerIntRegister(), TimerIntUnregister(), TimerLoadGet(), TimerLoadSet(), TimerMatchGet(), TimerMatchSet(), TimerPrescaleGet(), TimerPrescaleMatchGet(), TimerPrescaleMatchSet(), TimerPrescaleSet(), TimerUpdateMode(), and TimerValueGet().
| #define TIMER_B 0x0000ff00 |
Definition at line 153 of file timer.h.
Referenced by _TimerIntNumberGet(), TimerControlEvent(), TimerControlLevel(), TimerControlStall(), TimerControlTrigger(), TimerControlWaitOnTrigger(), TimerDisable(), TimerEnable(), TimerIntRegister(), TimerIntUnregister(), TimerLoadGet(), TimerLoadSet(), TimerMatchGet(), TimerMatchSet(), TimerPrescaleGet(), TimerPrescaleMatchGet(), TimerPrescaleMatchSet(), TimerPrescaleSet(), TimerUpdateMode(), and TimerValueGet().
| #define TIMER_BOTH 0x0000ffff |
Definition at line 154 of file timer.h.
Referenced by TimerControlEvent(), TimerControlLevel(), TimerControlStall(), TimerControlTrigger(), TimerControlWaitOnTrigger(), TimerDisable(), TimerEnable(), TimerIntRegister(), TimerIntUnregister(), TimerLoadSet(), TimerMatchSet(), TimerPrescaleGet(), TimerPrescaleMatchGet(), TimerPrescaleMatchSet(), and TimerPrescaleSet().
| #define TIMER_CFG_A_CAP_COUNT 0x00000003 |
Definition at line 71 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_A_CAP_TIME 0x00000007 |
Definition at line 73 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_A_ONE_SHOT 0x00000021 |
Definition at line 67 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_A_ONE_SHOT_UP 0x00000031 |
Definition at line 68 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_A_PERIODIC 0x00000022 |
Definition at line 69 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_A_PERIODIC_UP 0x00000032 |
Definition at line 70 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_A_PWM 0x0000000A |
Definition at line 75 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_CAP_COUNT 0x00000300 |
Definition at line 80 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_CAP_COUNT_UP 0x00001300 |
Definition at line 81 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_CAP_TIME 0x00000700 |
Definition at line 82 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_CAP_TIME_UP 0x00001700 |
Definition at line 83 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_ONE_SHOT 0x00002100 |
Definition at line 76 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_ONE_SHOT_UP 0x00003100 |
Definition at line 77 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_PERIODIC 0x00002200 |
Definition at line 78 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_PERIODIC_UP 0x00003200 |
Definition at line 79 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_B_PWM 0x00000A00 |
Definition at line 84 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_ONE_SHOT 0x00000021 |
Definition at line 59 of file timer.h.
Referenced by button_debounce_start(), main(), and TimerConfigure().
| #define TIMER_CFG_ONE_SHOT_UP 0x00000031 |
Definition at line 60 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_PERIODIC 0x00000022 |
Definition at line 62 of file timer.h.
Referenced by main(), and TimerConfigure().
| #define TIMER_CFG_PERIODIC_UP 0x00000032 |
Definition at line 63 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_RTC 0x01000000 |
Definition at line 65 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CFG_SPLIT_PAIR 0x04000000 |
Definition at line 66 of file timer.h.
Referenced by TimerConfigure().
| #define TIMER_CLOCK_PIOSC 0x00000001 |
Definition at line 193 of file timer.h.
Referenced by TimerClockSourceSet().
| #define TIMER_CLOCK_SYSTEM 0x00000000 |
Definition at line 192 of file timer.h.
Referenced by TimerClockSourceSet().
| #define TIMER_TIMA_TIMEOUT 0x00000001 |
Definition at line 135 of file timer.h.
Referenced by main(), sA_Handler(), TIMER0A_Handler(), TIMER1A_Handler(), TIMER2A_Handler(), timer_add_interrupt(), and timer_task().
