This graph shows which files directly or indirectly include this file:

Macros
#define	GPIO_PIN_0 0x00000001

#define	GPIO_PIN_1 0x00000002

#define	GPIO_PIN_2 0x00000004

#define	GPIO_PIN_3 0x00000008

#define	GPIO_PIN_4 0x00000010

#define	GPIO_PIN_5 0x00000020

#define	GPIO_PIN_6 0x00000040

#define	GPIO_PIN_7 0x00000080

#define	GPIO_DIR_MODE_IN 0x00000000

#define	GPIO_DIR_MODE_OUT 0x00000001

#define	GPIO_DIR_MODE_HW 0x00000002

#define	GPIO_FALLING_EDGE 0x00000000

#define	GPIO_RISING_EDGE 0x00000004

#define	GPIO_BOTH_EDGES 0x00000001

#define	GPIO_LOW_LEVEL 0x00000002

#define	GPIO_HIGH_LEVEL 0x00000006

#define	GPIO_DISCRETE_INT 0x00010000

#define	GPIO_STRENGTH_2MA 0x00000001

#define	GPIO_STRENGTH_4MA 0x00000002

#define	GPIO_STRENGTH_6MA 0x00000065

#define	GPIO_STRENGTH_8MA 0x00000066

#define	GPIO_STRENGTH_8MA_SC 0x0000006E

#define	GPIO_STRENGTH_10MA 0x00000075

#define	GPIO_STRENGTH_12MA 0x00000077

#define	GPIO_PIN_TYPE_STD 0x00000008

#define	GPIO_PIN_TYPE_STD_WPU 0x0000000A

#define	GPIO_PIN_TYPE_STD_WPD 0x0000000C

#define	GPIO_PIN_TYPE_OD 0x00000009

#define	GPIO_PIN_TYPE_ANALOG 0x00000000

#define	GPIO_PIN_TYPE_WAKE_HIGH 0x00000208

#define	GPIO_PIN_TYPE_WAKE_LOW 0x00000108

#define	GPIO_INT_PIN_0 0x00000001

#define	GPIO_INT_PIN_1 0x00000002

#define	GPIO_INT_PIN_2 0x00000004

#define	GPIO_INT_PIN_3 0x00000008

#define	GPIO_INT_PIN_4 0x00000010

#define	GPIO_INT_PIN_5 0x00000020

#define	GPIO_INT_PIN_6 0x00000040

#define	GPIO_INT_PIN_7 0x00000080

#define	GPIO_INT_DMA 0x00000100

Functions
void	GPIODirModeSet (uint32_t ui32Port, uint8_t ui8Pins, uint32_t ui32PinIO)

uint32_t	GPIODirModeGet (uint32_t ui32Port, uint8_t ui8Pin)

void	GPIOIntTypeSet (uint32_t ui32Port, uint8_t ui8Pins, uint32_t ui32IntType)

uint32_t	GPIOIntTypeGet (uint32_t ui32Port, uint8_t ui8Pin)

void	GPIOPadConfigSet (uint32_t ui32Port, uint8_t ui8Pins, uint32_t ui32Strength, uint32_t ui32PadType)

void	GPIOPadConfigGet (uint32_t ui32Port, uint8_t ui8Pin, uint32_t pui32Strength, uint32_t pui32PadType)

void	GPIOIntEnable (uint32_t ui32Port, uint32_t ui32IntFlags)

void	GPIOIntDisable (uint32_t ui32Port, uint32_t ui32IntFlags)

uint32_t	GPIOIntStatus (uint32_t ui32Port, bool bMasked)

void	GPIOIntClear (uint32_t ui32Port, uint32_t ui32IntFlags)

void	GPIOIntRegister (uint32_t ui32Port, void(*pfnIntHandler)(void))

void	GPIOIntUnregister (uint32_t ui32Port)

int32_t	GPIOPinRead (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinWrite (uint32_t ui32Port, uint8_t ui8Pins, uint8_t ui8Val)

void	GPIOPinConfigure (uint32_t ui32PinConfig)

void	GPIOPinTypeADC (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeCAN (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeComparator (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeEPI (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeEthernetLED (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeEthernetMII (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeGPIOInput (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeGPIOOutput (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeGPIOOutputOD (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeI2C (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeI2CSCL (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeLCD (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypePWM (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeQEI (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeSSI (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeTimer (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeUART (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeUSBAnalog (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeUSBDigital (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeWakeHigh (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOPinTypeWakeLow (uint32_t ui32Port, uint8_t ui8Pins)

uint32_t	GPIOPinWakeStatus (uint32_t ui32Port)

void	GPIODMATriggerEnable (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIODMATriggerDisable (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOADCTriggerEnable (uint32_t ui32Port, uint8_t ui8Pins)

void	GPIOADCTriggerDisable (uint32_t ui32Port, uint8_t ui8Pins)
