Sysexc_api

Functions
static uint32_t	_SysExcIntNumberGet (void)
void	SysExcIntRegister (void(*pfnHandler)(void))
void	SysExcIntUnregister (void)
void	SysExcIntEnable (uint32_t ui32IntFlags)
void	SysExcIntDisable (uint32_t ui32IntFlags)
uint32_t	SysExcIntStatus (bool bMasked)
void	SysExcIntClear (uint32_t ui32IntFlags)

Detailed Description

Function Documentation

static uint32_t _SysExcIntNumberGet ( void  )

static

Returns the interrupt number for a system exception.

This function returns the interrupt number for a system exception.

Returns

Returns the system exception interrupt number.

Definition at line 66 of file sysexc.c.

References CLASS_IS_TM4C123, CLASS_IS_TM4C129, INT_SYSEXC_TM4C123, and INT_SYSEXC_TM4C129.

Referenced by SysExcIntRegister(), and SysExcIntUnregister().

{
    uint32_t ui32Int;

    //
    // Get the interrupt number based on the class.
    //
    if(CLASS_IS_TM4C123)
    {
        ui32Int = INT_SYSEXC_TM4C123;
    }
    else if(CLASS_IS_TM4C129)
    {
        ui32Int = INT_SYSEXC_TM4C129;
    }
    else
    {
        ui32Int = 0;
    }
    return(ui32Int);
}

Here is the caller graph for this function:

void SysExcIntClear

(

uint32_t

ui32IntFlags

)

Clears system exception interrupt sources.

Parameters

ui32IntFlags

is a bit mask of the interrupt sources to be cleared.

This function clears the specified system exception interrupt sources, so that they no longer assert. This function must be called in the interrupt handler to keep the interrupt from being recognized again immediately upon exit.

The ui32IntFlags parameter is the logical OR of any of the following:

• SYSEXC_INT_FP_IXC - Floating-point inexact exception interrupt
• SYSEXC_INT_FP_OFC - Floating-point overflow exception interrupt
• SYSEXC_INT_FP_UFC - Floating-point underflow exception interrupt
• SYSEXC_INT_FP_IOC - Floating-point invalid operation interrupt
• SYSEXC_INT_FP_DZC - Floating-point divide by zero exception interrupt
• SYSEXC_INT_FP_IDC - Floating-point input denormal exception interrupt

Note

Because there is a write buffer in the Cortex-M processor, it may take several clock cycles before the interrupt source is actually cleared. Therefore, it is recommended that the interrupt source be cleared early in the interrupt handler (as opposed to the very last action) to avoid returning from the interrupt handler before the interrupt source is actually cleared. Failure to do so may result in the interrupt handler being immediately reentered (because the interrupt controller still sees the interrupt source asserted).

Returns

None.

Definition at line 298 of file sysexc.c.

References HWREG, and SYSEXC_IC.

{
    //
    // Clear the requested interrupt sources.
    //
    HWREG(SYSEXC_IC) = ui32IntFlags;
}

void SysExcIntDisable

(

uint32_t

ui32IntFlags

)

Disables individual system exception interrupt sources.

Parameters

ui32IntFlags

is the bit mask of the interrupt sources to be disabled.

This function disables the indicated system exception interrupt sources. Only sources that are enabled can be reflected to the processor interrupt; disabled sources have no effect on the processor.

The ui32IntFlags parameter is the logical OR of any of the following:

• SYSEXC_INT_FP_IXC - Floating-point inexact exception interrupt
• SYSEXC_INT_FP_OFC - Floating-point overflow exception interrupt
• SYSEXC_INT_FP_UFC - Floating-point underflow exception interrupt
• SYSEXC_INT_FP_IOC - Floating-point invalid operation interrupt
• SYSEXC_INT_FP_DZC - Floating-point divide by zero exception interrupt
• SYSEXC_INT_FP_IDC - Floating-point input denormal exception interrupt

Returns

None.

Definition at line 223 of file sysexc.c.

References HWREG, and SYSEXC_IM.

{
    //
    // Disable the specified interrupts.
    //
    HWREG(SYSEXC_IM) &= ~(ui32IntFlags);
}

void SysExcIntEnable

(

uint32_t

ui32IntFlags

)

Enables individual system exception interrupt sources.

Parameters

ui32IntFlags

is the bit mask of the interrupt sources to be enabled.

This function enables the indicated system exception interrupt sources. Only the sources that are enabled can be reflected to the processor interrupt; disabled sources have no effect on the processor.

The ui32IntFlags parameter is the logical OR of any of the following:

• SYSEXC_INT_FP_IXC - Floating-point inexact exception interrupt
• SYSEXC_INT_FP_OFC - Floating-point overflow exception interrupt
• SYSEXC_INT_FP_UFC - Floating-point underflow exception interrupt
• SYSEXC_INT_FP_IOC - Floating-point invalid operation interrupt
• SYSEXC_INT_FP_DZC - Floating-point divide by zero exception interrupt
• SYSEXC_INT_FP_IDC - Floating-point input denormal exception interrupt

Returns

None.

Definition at line 191 of file sysexc.c.

References HWREG, and SYSEXC_IM.

{
    //
    // Enable the specified interrupts.
    //
    HWREG(SYSEXC_IM) |= ui32IntFlags;
}

void SysExcIntRegister

(

void(*)(void)

pfnHandler

)

Registers an interrupt handler for the system exception interrupt.

Parameters

pfnHandler

is a pointer to the function to be called when the system exception interrupt occurs.

This function places the address of the system exception interrupt handler into the interrupt vector table in SRAM. This function also enables the global interrupt in the interrupt controller; specific system exception interrupts must be enabled via SysExcIntEnable(). It is the interrupt handler's responsibility to clear the interrupt source.

See also

IntRegister() for important information about registering interrupt handlers.

Returns

None.

Definition at line 108 of file sysexc.c.

References _SysExcIntNumberGet(), ASSERT, IntEnable(), and IntRegister().

{
    uint32_t ui32Int;

    //
    // Get the system exception interrupt number.
    //
    ui32Int = _SysExcIntNumberGet();

    ASSERT(ui32Int != 0);

    //
    // Register the interrupt handler.
    //
    IntRegister(ui32Int, pfnHandler);

    //
    // Enable the system exception interrupt.
    //
    IntEnable(ui32Int);
}

Here is the call graph for this function:

uint32_t SysExcIntStatus

(

bool

bMasked

)

Gets the current system exception interrupt status.

Parameters

bMasked

is false if the raw interrupt status is required and true if the masked interrupt status is required.

This function returns the system exception interrupt status. Either the raw interrupt status or the status of interrupts that are allowed to reflect to the processor can be returned.

Returns

Returns the current system exception interrupt status, enumerated as the logical OR of SYSEXC_INT_FP_IXC, SYSEXC_INT_FP_OFC, SYSEXC_INT_FP_UFC, SYSEXC_INT_FP_IOC, SYSEXC_INT_FP_DZC, and SYSEXC_INT_FP_IDC.

Definition at line 249 of file sysexc.c.

References HWREG, SYSEXC_MIS, and SYSEXC_RIS.

{
    //
    // Return either the interrupt status or the raw interrupt status as
    // requested.
    //
    if(bMasked)
    {
        return(HWREG(SYSEXC_MIS));
    }
    else
    {
        return(HWREG(SYSEXC_RIS));
    }
}

void SysExcIntUnregister

(

void

)

Unregisters the system exception interrupt handler.

This function removes the system exception interrupt handler from the vector table in SRAM. This function also masks off the system exception interrupt in the interrupt controller so that the interrupt handler is no longer called.

See also

IntRegister() for important information about registering interrupt handlers.

Returns

None.

Definition at line 146 of file sysexc.c.

References _SysExcIntNumberGet(), ASSERT, IntDisable(), and IntUnregister().

{
    uint32_t ui32Int;

    //
    // Get the system exception interrupt number.
    //
    ui32Int = _SysExcIntNumberGet();

    ASSERT(ui32Int != 0);

    //
    // Disable the system exception interrupt.
    //
    IntDisable(ui32Int);

    //
    // Unregister the system exception interrupt handler.
    //
    IntUnregister(ui32Int);
}

Here is the call graph for this function:
