Macros | Functions | Variables
adc.c File Reference
#include <stdbool.h>
#include <stdint.h>
#include "inc/hw_adc.h"
#include "inc/hw_ints.h"
#include "inc/hw_memmap.h"
#include "inc/hw_types.h"
#include "inc/hw_sysctl.h"
#include "driverlib/adc.h"
#include "driverlib/debug.h"
#include "driverlib/interrupt.h"
Include dependency graph for adc.c:

Go to the source code of this file.

Macros

#define ADC_SEQ   (ADC_O_SSMUX0)

#define ADC_SEQ_STEP   (ADC_O_SSMUX1 - ADC_O_SSMUX0)

#define ADC_SSMUX   (ADC_O_SSMUX0 - ADC_O_SSMUX0)

#define ADC_SSEMUX   (ADC_O_SSEMUX0 - ADC_O_SSMUX0)

#define ADC_SSCTL   (ADC_O_SSCTL0 - ADC_O_SSMUX0)

#define ADC_SSFIFO   (ADC_O_SSFIFO0 - ADC_O_SSMUX0)

#define ADC_SSFSTAT   (ADC_O_SSFSTAT0 - ADC_O_SSMUX0)

#define ADC_SSOP   (ADC_O_SSOP0 - ADC_O_SSMUX0)

#define ADC_SSDC   (ADC_O_SSDC0 - ADC_O_SSMUX0)

#define ADC_SSTSH   (ADC_O_SSTSH0 - ADC_O_SSMUX0)


Functions

static uint_fast8_t _ADCIntNumberGet (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCIntRegister (uint32_t ui32Base, uint32_t ui32SequenceNum, void(*pfnHandler)(void))

void ADCIntUnregister (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCIntDisable (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCIntEnable (uint32_t ui32Base, uint32_t ui32SequenceNum)

uint32_t ADCIntStatus (uint32_t ui32Base, uint32_t ui32SequenceNum, bool bMasked)

void ADCIntClear (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCSequenceEnable (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCSequenceDisable (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCSequenceConfigure (uint32_t ui32Base, uint32_t ui32SequenceNum, uint32_t ui32Trigger, uint32_t ui32Priority)

void ADCSequenceStepConfigure (uint32_t ui32Base, uint32_t ui32SequenceNum, uint32_t ui32Step, uint32_t ui32Config)

int32_t ADCSequenceOverflow (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCSequenceOverflowClear (uint32_t ui32Base, uint32_t ui32SequenceNum)

int32_t ADCSequenceUnderflow (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCSequenceUnderflowClear (uint32_t ui32Base, uint32_t ui32SequenceNum)

int32_t ADCSequenceDataGet (uint32_t ui32Base, uint32_t ui32SequenceNum, uint32_t *pui32Buffer)

void ADCProcessorTrigger (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCSoftwareOversampleConfigure (uint32_t ui32Base, uint32_t ui32SequenceNum, uint32_t ui32Factor)

void ADCSoftwareOversampleStepConfigure (uint32_t ui32Base, uint32_t ui32SequenceNum, uint32_t ui32Step, uint32_t ui32Config)

void ADCSoftwareOversampleDataGet (uint32_t ui32Base, uint32_t ui32SequenceNum, uint32_t *pui32Buffer, uint32_t ui32Count)

void ADCHardwareOversampleConfigure (uint32_t ui32Base, uint32_t ui32Factor)

void ADCComparatorConfigure (uint32_t ui32Base, uint32_t ui32Comp, uint32_t ui32Config)

void ADCComparatorRegionSet (uint32_t ui32Base, uint32_t ui32Comp, uint32_t ui32LowRef, uint32_t ui32HighRef)

void ADCComparatorReset (uint32_t ui32Base, uint32_t ui32Comp, bool bTrigger, bool bInterrupt)

void ADCComparatorIntDisable (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCComparatorIntEnable (uint32_t ui32Base, uint32_t ui32SequenceNum)

uint32_t ADCComparatorIntStatus (uint32_t ui32Base)

void ADCComparatorIntClear (uint32_t ui32Base, uint32_t ui32Status)

void ADCIntDisableEx (uint32_t ui32Base, uint32_t ui32IntFlags)

void ADCIntEnableEx (uint32_t ui32Base, uint32_t ui32IntFlags)

uint32_t ADCIntStatusEx (uint32_t ui32Base, bool bMasked)

void ADCIntClearEx (uint32_t ui32Base, uint32_t ui32IntFlags)

void ADCReferenceSet (uint32_t ui32Base, uint32_t ui32Ref)

uint32_t ADCReferenceGet (uint32_t ui32Base)

void ADCPhaseDelaySet (uint32_t ui32Base, uint32_t ui32Phase)

uint32_t ADCPhaseDelayGet (uint32_t ui32Base)

void ADCSequenceDMAEnable (uint32_t ui32Base, uint32_t ui32SequenceNum)

void ADCSequenceDMADisable (uint32_t ui32Base, uint32_t ui32SequenceNum)

bool ADCBusy (uint32_t ui32Base)

void ADCClockConfigSet (uint32_t ui32Base, uint32_t ui32Config, uint32_t ui32ClockDiv)

uint32_t ADCClockConfigGet (uint32_t ui32Base, uint32_t *pui32ClockDiv)


Variables

static uint8_t g_pui8OversampleFactor [3]
