EE445M RTOS
Taken at the University of Texas Spring 2015
Macros | Functions
pwm.c File Reference
#include <stdbool.h>
#include <stdint.h>
#include "inc/hw_ints.h"
#include "inc/hw_memmap.h"
#include "inc/hw_pwm.h"
#include "inc/hw_sysctl.h"
#include "inc/hw_types.h"
#include "driverlib/debug.h"
#include "driverlib/interrupt.h"
#include "driverlib/pwm.h"
Include dependency graph for pwm.c:

Go to the source code of this file.

Macros

#define PWM_GEN_BADDR(_mod_, _gen_)   ((_mod_) + (_gen_))

#define PWM_GEN_EXT_BADDR(_mod_, _gen_)

#define PWM_OUT_BADDR(_mod_, _out_)   ((_mod_) + ((_out_) & 0xFFFFFFC0))

#define PWM_IS_OUTPUT_ODD(_out_)   ((_out_) & 0x00000001)


Functions

void PWMGenConfigure (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32Config)

void PWMGenPeriodSet (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32Period)

uint32_t PWMGenPeriodGet (uint32_t ui32Base, uint32_t ui32Gen)

void PWMGenEnable (uint32_t ui32Base, uint32_t ui32Gen)

void PWMGenDisable (uint32_t ui32Base, uint32_t ui32Gen)

void PWMPulseWidthSet (uint32_t ui32Base, uint32_t ui32PWMOut, uint32_t ui32Width)

uint32_t PWMPulseWidthGet (uint32_t ui32Base, uint32_t ui32PWMOut)

void PWMDeadBandEnable (uint32_t ui32Base, uint32_t ui32Gen, uint16_t ui16Rise, uint16_t ui16Fall)

void PWMDeadBandDisable (uint32_t ui32Base, uint32_t ui32Gen)

void PWMSyncUpdate (uint32_t ui32Base, uint32_t ui32GenBits)

void PWMSyncTimeBase (uint32_t ui32Base, uint32_t ui32GenBits)

void PWMOutputState (uint32_t ui32Base, uint32_t ui32PWMOutBits, bool bEnable)

void PWMOutputInvert (uint32_t ui32Base, uint32_t ui32PWMOutBits, bool bInvert)

void PWMOutputFaultLevel (uint32_t ui32Base, uint32_t ui32PWMOutBits, bool bDriveHigh)

void PWMOutputFault (uint32_t ui32Base, uint32_t ui32PWMOutBits, bool bFaultSuppress)

static uint32_t _PWMGenIntNumberGet (uint32_t ui32Base, uint32_t ui32Gen)

void PWMGenIntRegister (uint32_t ui32Base, uint32_t ui32Gen, void(*pfnIntHandler)(void))

void PWMGenIntUnregister (uint32_t ui32Base, uint32_t ui32Gen)

static uint32_t _PWMFaultIntNumberGet (uint32_t ui32Base)

void PWMFaultIntRegister (uint32_t ui32Base, void(*pfnIntHandler)(void))

void PWMFaultIntUnregister (uint32_t ui32Base)

void PWMGenIntTrigEnable (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32IntTrig)

void PWMGenIntTrigDisable (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32IntTrig)

uint32_t PWMGenIntStatus (uint32_t ui32Base, uint32_t ui32Gen, bool bMasked)

void PWMGenIntClear (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32Ints)

void PWMIntEnable (uint32_t ui32Base, uint32_t ui32GenFault)

void PWMIntDisable (uint32_t ui32Base, uint32_t ui32GenFault)

void PWMFaultIntClear (uint32_t ui32Base)

uint32_t PWMIntStatus (uint32_t ui32Base, bool bMasked)

void PWMFaultIntClearExt (uint32_t ui32Base, uint32_t ui32FaultInts)

void PWMGenFaultConfigure (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32MinFaultPeriod, uint32_t ui32FaultSenses)

void PWMGenFaultTriggerSet (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32Group, uint32_t ui32FaultTriggers)

uint32_t PWMGenFaultTriggerGet (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32Group)

uint32_t PWMGenFaultStatus (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32Group)

void PWMGenFaultClear (uint32_t ui32Base, uint32_t ui32Gen, uint32_t ui32Group, uint32_t ui32FaultTriggers)

void PWMClockSet (uint32_t ui32Base, uint32_t ui32Config)

uint32_t PWMClockGet (uint32_t ui32Base)

void PWMOutputUpdateMode (uint32_t ui32Base, uint32_t ui32PWMOutBits, uint32_t ui32Mode)
