Qei_api

Functions
void	QEIEnable (uint32_t ui32Base)
void	QEIDisable (uint32_t ui32Base)
void	QEIConfigure (uint32_t ui32Base, uint32_t ui32Config, uint32_t ui32MaxPosition)
uint32_t	QEIPositionGet (uint32_t ui32Base)
void	QEIPositionSet (uint32_t ui32Base, uint32_t ui32Position)
int32_t	QEIDirectionGet (uint32_t ui32Base)
bool	QEIErrorGet (uint32_t ui32Base)
void	QEIVelocityEnable (uint32_t ui32Base)
void	QEIVelocityDisable (uint32_t ui32Base)
void	QEIVelocityConfigure (uint32_t ui32Base, uint32_t ui32PreDiv, uint32_t ui32Period)
uint32_t	QEIVelocityGet (uint32_t ui32Base)
static uint32_t	_QEIIntNumberGet (uint32_t ui32Base)
void	QEIIntRegister (uint32_t ui32Base, void(*pfnHandler)(void))
void	QEIIntUnregister (uint32_t ui32Base)
void	QEIIntEnable (uint32_t ui32Base, uint32_t ui32IntFlags)
void	QEIIntDisable (uint32_t ui32Base, uint32_t ui32IntFlags)
uint32_t	QEIIntStatus (uint32_t ui32Base, bool bMasked)
void	QEIIntClear (uint32_t ui32Base, uint32_t ui32IntFlags)

Detailed Description

Function Documentation

static uint32_t _QEIIntNumberGet ( uint32_t  ui32Base )

static

Returns the quadrature encoder interrupt number.

Parameters

ui32Base

is the base address of the selected quadrature encoder

This function returns the interrupt number for the quadrature encoder with the base address passed in the ui32Base parameter.

Returns

Returns a quadrature encoder interrupt number or 0 if the interrupt does not exist.

Definition at line 419 of file qei.c.

References ASSERT, CLASS_IS_TM4C123, CLASS_IS_TM4C129, INT_QEI0_TM4C123, INT_QEI0_TM4C129, INT_QEI1_TM4C123, QEI0_BASE, and QEI1_BASE.

Referenced by QEIIntRegister(), and QEIIntUnregister().

{
    uint32_t ui32Int;

    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Find the valid interrupt number for this quadrature encoder.
    //
    if(CLASS_IS_TM4C123)
    {
        if(ui32Base == QEI0_BASE)
        {
            ui32Int = INT_QEI0_TM4C123;
        }
        else
        {
            ui32Int = INT_QEI1_TM4C123;
        }
    }
    else if(CLASS_IS_TM4C129)
    {
        if(ui32Base == QEI0_BASE)
        {
            ui32Int = INT_QEI0_TM4C129;
        }
        else
        {
            ui32Int = 0;
        }
    }
    else
    {
        ui32Int = 0;
    }

    return(ui32Int);
}

Here is the caller graph for this function:

void QEIConfigure	(	uint32_t	ui32Base,
		uint32_t	ui32Config,
		uint32_t	ui32MaxPosition
	)

Configures the quadrature encoder.

Parameters

ui32Base	is the base address of the quadrature encoder module.
ui32Config	is the configuration for the quadrature encoder. See below for a description of this parameter.
ui32MaxPosition	specifies the maximum position value.

This function configures the operation of the quadrature encoder. The ui32Config parameter provides the configuration of the encoder and is the logical OR of several values:

• QEI_CONFIG_CAPTURE_A or QEI_CONFIG_CAPTURE_A_B specify if edges on channel A or on both channels A and B should be counted by the position integrator and velocity accumulator.
• QEI_CONFIG_NO_RESET or QEI_CONFIG_RESET_IDX specify if the position integrator should be reset when the index pulse is detected.
• QEI_CONFIG_QUADRATURE or QEI_CONFIG_CLOCK_DIR specify if quadrature signals are being provided on ChA and ChB, or if a direction signal and a clock are being provided instead.
• QEI_CONFIG_NO_SWAP or QEI_CONFIG_SWAP to specify if the signals provided on ChA and ChB should be swapped before being processed.

ui32MaxPosition is the maximum value of the position integrator and is the value used to reset the position capture when in index reset mode and moving in the reverse (negative) direction.

Returns

None.

Definition at line 143 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_CTL_CAPMODE, QEI_CTL_RESMODE, QEI_CTL_SIGMODE, QEI_CTL_SWAP, QEI_O_CTL, and QEI_O_MAXPOS.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Write the new configuration to the hardware.
    //
    HWREG(ui32Base + QEI_O_CTL) = ((HWREG(ui32Base + QEI_O_CTL) &
                                    ~(QEI_CTL_CAPMODE | QEI_CTL_RESMODE |
                                      QEI_CTL_SIGMODE | QEI_CTL_SWAP)) |
                                   ui32Config);

    //
    // Set the maximum position.
    //
    HWREG(ui32Base + QEI_O_MAXPOS) = ui32MaxPosition;
}

int32_t QEIDirectionGet

(

uint32_t

ui32Base

)

Gets the current direction of rotation.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function returns the current direction of rotation. In this case, current means the most recently detected direction of the encoder; it may not be presently moving but this is the direction it last moved before it stopped.

Returns

Returns 1 if moving in the forward direction or -1 if moving in the reverse direction.

Definition at line 237 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_O_STAT, and QEI_STAT_DIRECTION.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Return the direction of rotation.
    //
    return((HWREG(ui32Base + QEI_O_STAT) & QEI_STAT_DIRECTION) ? -1 : 1);
}

void QEIDisable

(

uint32_t

ui32Base

)

Disables the quadrature encoder.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function disables operation of the quadrature encoder module.

Returns

None.

Definition at line 98 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_CTL_ENABLE, and QEI_O_CTL.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Disable the QEI module.
    //
    HWREG(ui32Base + QEI_O_CTL) &= ~(QEI_CTL_ENABLE);
}

void QEIEnable

(

uint32_t

ui32Base

)

Enables the quadrature encoder.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function enables operation of the quadrature encoder module. The module must be configured before it is enabled.

See also

QEIConfigure()

Returns

None.

Definition at line 73 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_CTL_ENABLE, and QEI_O_CTL.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Enable the QEI module.
    //
    HWREG(ui32Base + QEI_O_CTL) |= QEI_CTL_ENABLE;
}

bool QEIErrorGet

(

uint32_t

ui32Base

)

Gets the encoder error indicator.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function returns the error indicator for the quadrature encoder. It is an error for both of the signals of the quadrature input to change at the same time.

Returns

Returns true if an error has occurred and false otherwise.

Definition at line 264 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_O_STAT, and QEI_STAT_ERROR.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Return the error indicator.
    //
    return((HWREG(ui32Base + QEI_O_STAT) & QEI_STAT_ERROR) ? true : false);
}

void QEIIntClear	(	uint32_t	ui32Base,
		uint32_t	ui32IntFlags
	)

Clears quadrature encoder interrupt sources.

Parameters

ui32Base	is the base address of the quadrature encoder module.
ui32IntFlags	is a bit mask of the interrupt sources to be cleared. This parameter can be any of the QEI_INTERROR, QEI_INTDIR, QEI_INTTIMER, or QEI_INTINDEX values.

The specified quadrature encoder interrupt sources are cleared, so that they no longer assert. This function must be called in the interrupt handler to keep the interrupt from being triggered again immediately upon exit.

Note

Because there is a write buffer in the Cortex-M processor, it may take several clock cycles before the interrupt source is actually cleared. Therefore, it is recommended that the interrupt source be cleared early in the interrupt handler (as opposed to the very last action) to avoid returning from the interrupt handler before the interrupt source is actually cleared. Failure to do so may result in the interrupt handler being immediately reentered (because the interrupt controller still sees the interrupt source asserted).

Returns

None.

Definition at line 675 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, and QEI_O_ISC.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Clear the requested interrupt sources.
    //
    HWREG(ui32Base + QEI_O_ISC) = ui32IntFlags;
}

void QEIIntDisable	(	uint32_t	ui32Base,
		uint32_t	ui32IntFlags
	)

Disables individual quadrature encoder interrupt sources.

Parameters

ui32Base	is the base address of the quadrature encoder module.
ui32IntFlags	is a bit mask of the interrupt sources to be disabled. This parameter can be any of the QEI_INTERROR, QEI_INTDIR, QEI_INTTIMER, or QEI_INTINDEX values.

This function disables the indicated quadrature encoder interrupt sources. Only the sources that are enabled can be reflected to the processor interrupt; disabled sources have no effect on the processor.

Returns

None.

Definition at line 597 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, and QEI_O_INTEN.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Disable the specified interrupts.
    //
    HWREG(ui32Base + QEI_O_INTEN) &= ~(ui32IntFlags);
}

void QEIIntEnable	(	uint32_t	ui32Base,
		uint32_t	ui32IntFlags
	)

Enables individual quadrature encoder interrupt sources.

Parameters

ui32Base	is the base address of the quadrature encoder module.
ui32IntFlags	is a bit mask of the interrupt sources to be enabled. Can be any of the QEI_INTERROR, QEI_INTDIR, QEI_INTTIMER, or QEI_INTINDEX values.

This function enables the indicated quadrature encoder interrupt sources. Only the sources that are enabled can be reflected to the processor interrupt; disabled sources have no effect on the processor.

Returns

None.

Definition at line 567 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, and QEI_O_INTEN.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Enable the specified interrupts.
    //
    HWREG(ui32Base + QEI_O_INTEN) |= ui32IntFlags;
}

void QEIIntRegister	(	uint32_t	ui32Base,
		void(*)(void)	pfnHandler
	)

Registers an interrupt handler for the quadrature encoder interrupt.

Parameters

ui32Base	is the base address of the quadrature encoder module.
pfnHandler	is a pointer to the function to be called when the quadrature encoder interrupt occurs.

This function registers the handler to be called when a quadrature encoder interrupt occurs. This function enables the global interrupt in the interrupt controller; specific quadrature encoder interrupts must be enabled via QEIIntEnable(). It is the interrupt handler's responsibility to clear the interrupt source via QEIIntClear().

See also

IntRegister() for important information about registering interrupt handlers.

Returns

None.

Definition at line 479 of file qei.c.

References _QEIIntNumberGet(), ASSERT, IntEnable(), IntRegister(), QEI0_BASE, and QEI1_BASE.

{
    uint32_t ui32Int;

    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Determine the interrupt number based on the QEI module.
    //
    ui32Int = _QEIIntNumberGet(ui32Base);

    ASSERT(ui32Int != 0);

    //
    // Register the interrupt handler, returning an error if an error occurs.
    //
    IntRegister(ui32Int, pfnHandler);

    //
    // Enable the quadrature encoder interrupt.
    //
    IntEnable(ui32Int);
}

Here is the call graph for this function:

uint32_t QEIIntStatus	(	uint32_t	ui32Base,
		bool	bMasked
	)

Gets the current interrupt status.

Parameters

ui32Base	is the base address of the quadrature encoder module.
bMasked	is false if the raw interrupt status is required and true if the masked interrupt status is required.

This function returns the interrupt status for the quadrature encoder module. Either the raw interrupt status or the status of interrupts that are allowed to reflect to the processor can be returned.

Returns

Returns the current interrupt status, enumerated as a bit field of QEI_INTERROR, QEI_INTDIR, QEI_INTTIMER, and QEI_INTINDEX.

Definition at line 627 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_O_ISC, and QEI_O_RIS.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Return either the interrupt status or the raw interrupt status as
    // requested.
    //
    if(bMasked)
    {
        return(HWREG(ui32Base + QEI_O_ISC));
    }
    else
    {
        return(HWREG(ui32Base + QEI_O_RIS));
    }
}

void QEIIntUnregister

(

uint32_t

ui32Base

)

Unregisters an interrupt handler for the quadrature encoder interrupt.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function unregisters the handler to be called when a quadrature encoder interrupt occurs. This function also masks off the interrupt in the interrupt controller so that the interrupt handler no longer is called.

See also

IntRegister() for important information about registering interrupt handlers.

Returns

None.

Definition at line 523 of file qei.c.

References _QEIIntNumberGet(), ASSERT, IntDisable(), IntUnregister(), QEI0_BASE, and QEI1_BASE.

{
    uint32_t ui32Int;

    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Determine the interrupt number based on the QEI module.
    //
    ui32Int = _QEIIntNumberGet(ui32Base);

    ASSERT(ui32Int != 0);

    //
    // Disable the interrupt.
    //
    IntDisable(ui32Int);

    //
    // Unregister the interrupt handler.
    //
    IntUnregister(ui32Int);
}

Here is the call graph for this function:

uint32_t QEIPositionGet

(

uint32_t

ui32Base

)

Gets the current encoder position.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function returns the current position of the encoder. Depending upon the configuration of the encoder, and the incident of an index pulse, this value may or may not contain the expected data (that is, if in reset on index mode, if an index pulse has not been encountered, the position counter is not yet aligned with the index pulse).

Returns

The current position of the encoder.

Definition at line 181 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, and QEI_O_POS.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Return the current position counter.
    //
    return(HWREG(ui32Base + QEI_O_POS));
}

void QEIPositionSet	(	uint32_t	ui32Base,
		uint32_t	ui32Position
	)

Sets the current encoder position.

Parameters

ui32Base	is the base address of the quadrature encoder module.
ui32Position	is the new position for the encoder.

This function sets the current position of the encoder; the encoder position is then measured relative to this value.

Returns

None.

Definition at line 208 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, and QEI_O_POS.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Set the position counter.
    //
    HWREG(ui32Base + QEI_O_POS) = ui32Position;
}

void QEIVelocityConfigure	(	uint32_t	ui32Base,
		uint32_t	ui32PreDiv,
		uint32_t	ui32Period
	)

Configures the velocity capture.

Parameters

ui32Base	is the base address of the quadrature encoder module.
ui32PreDiv	specifies the predivider applied to the input quadrature signal before it is counted; can be one of QEI_VELDIV_1, QEI_VELDIV_2, QEI_VELDIV_4, QEI_VELDIV_8, QEI_VELDIV_16, QEI_VELDIV_32, QEI_VELDIV_64, or QEI_VELDIV_128.
ui32Period	specifies the number of clock ticks over which to measure the velocity; must be non-zero.

This function configures the operation of the velocity capture portion of the quadrature encoder. The position increment signal is predivided as specified by ui32PreDiv before being accumulated by the velocity capture. The divided signal is accumulated over ui32Period system clock before being saved and resetting the accumulator.

Returns

None.

Definition at line 354 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_CTL_VELDIV_M, QEI_O_CTL, and QEI_O_LOAD.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));
    ASSERT(!(ui32PreDiv & ~(QEI_CTL_VELDIV_M)));
    ASSERT(ui32Period != 0);

    //
    // Set the velocity predivider.
    //
    HWREG(ui32Base + QEI_O_CTL) = ((HWREG(ui32Base + QEI_O_CTL) &
                                    ~(QEI_CTL_VELDIV_M)) | ui32PreDiv);

    //
    // Set the timer period.
    //
    HWREG(ui32Base + QEI_O_LOAD) = ui32Period - 1;
}

void QEIVelocityDisable

(

uint32_t

ui32Base

)

Disables the velocity capture.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function disables operation of the velocity capture in the quadrature encoder module.

Returns

None.

Definition at line 319 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_CTL_VELEN, and QEI_O_CTL.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Disable the velocity capture.
    //
    HWREG(ui32Base + QEI_O_CTL) &= ~(QEI_CTL_VELEN);
}

void QEIVelocityEnable

(

uint32_t

ui32Base

)

Enables the velocity capture.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function enables operation of the velocity capture in the quadrature encoder module. The module must be configured before velocity capture is enabled.

See also

QEIVelocityConfigure() and QEIEnable()

Returns

None.

Definition at line 293 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, QEI_CTL_VELEN, and QEI_O_CTL.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Enable the velocity capture.
    //
    HWREG(ui32Base + QEI_O_CTL) |= QEI_CTL_VELEN;
}

uint32_t QEIVelocityGet

(

uint32_t

ui32Base

)

Gets the current encoder speed.

Parameters

ui32Base

is the base address of the quadrature encoder module.

This function returns the current speed of the encoder. The value returned is the number of pulses detected in the specified time period; this number can be multiplied by the number of time periods per second and divided by the number of pulses per revolution to obtain the number of revolutions per second.

Returns

Returns the number of pulses captured in the given time period.

Definition at line 392 of file qei.c.

References ASSERT, HWREG, QEI0_BASE, QEI1_BASE, and QEI_O_SPEED.

{
    //
    // Check the arguments.
    //
    ASSERT((ui32Base == QEI0_BASE) || (ui32Base == QEI1_BASE));

    //
    // Return the speed capture value.
    //
    return(HWREG(ui32Base + QEI_O_SPEED));
}
