Shamd5_api

Functions
void	SHAMD5Reset (uint32_t ui32Base)
void	SHAMD5DMAEnable (uint32_t ui32Base)
void	SHAMD5DMADisable (uint32_t ui32Base)
uint32_t	SHAMD5IntStatus (uint32_t ui32Base, bool bMasked)
void	SHAMD5IntEnable (uint32_t ui32Base, uint32_t ui32IntFlags)
void	SHAMD5IntDisable (uint32_t ui32Base, uint32_t ui32IntFlags)
void	SHAMD5IntClear (uint32_t ui32Base, uint32_t ui32IntFlags)
void	SHAMD5IntRegister (uint32_t ui32Base, void(*pfnHandler)(void))
void	SHAMD5IntUnregister (uint32_t ui32Base)
void	SHAMD5HashLengthSet (uint32_t ui32Base, uint32_t ui32Length)
void	SHAMD5ConfigSet (uint32_t ui32Base, uint32_t ui32Mode)
bool	SHAMD5DataWriteNonBlocking (uint32_t ui32Base, uint32_t *pui32Src)
void	SHAMD5DataWrite (uint32_t ui32Base, uint32_t *pui32Src)
void	SHAMD5ResultRead (uint32_t ui32Base, uint32_t *pui32Dest)
static void	_SHAMD5DataWriteMultiple (uint32_t ui32Base, uint32_t *pui32DataSrc, uint32_t ui32DataLength)
void	SHAMD5DataProcess (uint32_t ui32Base, uint32_t *pui32DataSrc, uint32_t ui32DataLength, uint32_t *pui32HashResult)
void	SHAMD5HMACProcess (uint32_t ui32Base, uint32_t *pui32DataSrc, uint32_t ui32DataLength, uint32_t *pui32HashResult)
void	SHAMD5HMACPPKeyGenerate (uint32_t ui32Base, uint32_t *pui32Key, uint32_t *pui32PPKey)
void	SHAMD5HMACKeySet (uint32_t ui32Base, uint32_t *pui32Src)
void	SHAMD5HMACPPKeySet (uint32_t ui32Base, uint32_t *pui32Src)

Detailed Description

Function Documentation

static void _SHAMD5DataWriteMultiple ( uint32_t  ui32Base, uint32_t *  pui32DataSrc, uint32_t  ui32DataLength  )

static

Writes multiple words of data into the SHA/MD5 data registers.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32DataSrc	is a pointer to an array of data to be written.
ui32DataLength	is the length of the data to be written in bytes.

This function writes a variable number of words into the SHA/MD5 data registers. The function waits for each block of data to be processed before another is written. The ui32DataLength parameter must be a multiple of 4 to fall on a word boundry.

Note

This function is used by SHAMD5DataProcess() and SHAMD5HMACProcess() to process data.

Returns

None.

Definition at line 712 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_INPUT_READY, SHAMD5_O_DATA_0_IN, SHAMD5_O_IRQSTATUS, and SHAMD5DataWrite().

Referenced by SHAMD5DataProcess(), and SHAMD5HMACProcess().

{
    uint32_t ui32Idx, ui32Count;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Calculate the number of blocks of data.
    //
    ui32Count = ui32DataLength / 64;

    //
    // Loop through all the blocks and write them into the data registers
    // making sure to block additional operations until we can write the
    // next 16 words.
    //
    for(ui32Idx = 0; ui32Idx < ui32Count; ui32Idx++)
    {
        //
        // Write the block of data.
        //
        SHAMD5DataWrite(ui32Base, pui32DataSrc);

        //
        // Increment the pointer to next block of data.
        //
        pui32DataSrc += 16;
    }

    //
    // Calculate the remaining bytes of data that don't make up a full block.
    //
    ui32Count = ui32DataLength % 64;

    //
    // If there are bytes that do not make up a whole block, then
    // write them separately.
    //
    if(ui32Count)
    {
        //
        // Wait until the engine has finished processing the previous block.
        //
        while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) &
               SHAMD5_INT_INPUT_READY) == 0)
        {
        }

        //
        // Loop through the remaining words.
        //
        for(ui32Idx = 0; ui32Idx < ui32Count; ui32Idx += 4)
        {
            //
            // Write the word into the data register.
            //
            HWREG(ui32Base + SHAMD5_O_DATA_0_IN + ui32Idx) = *pui32DataSrc++;
        }
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void SHAMD5ConfigSet	(	uint32_t	ui32Base,
		uint32_t	ui32Mode
	)

Writes the mode in the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
ui32Mode	is the mode of the SHA/MD5 module.

This function writes the mode register configuring the SHA/MD5 module.

The ui32Mode parameter is a bit-wise OR of values:

• SHAMD5_ALGO_MD5 - Regular hash with MD5
• SHAMD5_ALGO_SHA1 - Regular hash with SHA-1
• SHAMD5_ALGO_SHA224 - Regular hash with SHA-224
• SHAMD5_ALGO_SHA256 - Regular hash with SHA-256
• SHAMD5_ALGO_HMAC_MD5 - HMAC with MD5
• SHAMD5_ALGO_HMAC_SHA1 - HMAC with SHA-1
• SHAMD5_ALGO_HMAC_SHA224 - HMAC with SHA-224
• SHAMD5_ALGO_HMAC_SHA256 - HMAC with SHA-256

Returns

None

Definition at line 469 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_ALGO_HMAC_MD5, SHAMD5_ALGO_HMAC_SHA1, SHAMD5_ALGO_HMAC_SHA224, SHAMD5_ALGO_HMAC_SHA256, SHAMD5_ALGO_MD5, SHAMD5_ALGO_SHA1, SHAMD5_ALGO_SHA224, SHAMD5_ALGO_SHA256, SHAMD5_BASE, and SHAMD5_O_MODE.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);
    ASSERT((ui32Mode == SHAMD5_ALGO_MD5) ||
           (ui32Mode == SHAMD5_ALGO_SHA1) ||
           (ui32Mode == SHAMD5_ALGO_SHA224) ||
           (ui32Mode == SHAMD5_ALGO_SHA256) ||
           (ui32Mode == SHAMD5_ALGO_HMAC_MD5) ||
           (ui32Mode == SHAMD5_ALGO_HMAC_SHA1) ||
           (ui32Mode == SHAMD5_ALGO_HMAC_SHA224) ||
           (ui32Mode == SHAMD5_ALGO_HMAC_SHA256));

    //
    // Write the value in the MODE register.
    //
    HWREG(ui32Base + SHAMD5_O_MODE) = ui32Mode;
}

void SHAMD5DataProcess	(	uint32_t	ui32Base,
		uint32_t *	pui32DataSrc,
		uint32_t	ui32DataLength,
		uint32_t *	pui32HashResult
	)

Compute a hash using the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32DataSrc	is a pointer to an array of data that contains the data that will be hashed.
ui32DataLength	specifies the length of the data to be hashed in bytes.
pui32HashResult	is a pointer to an array that holds the result of the hashing operation.

This function computes the hash of an array of data using the SHA/MD5 module.

The length of the hash result is dependent on the algorithm that is in use. The following table shows the correct array size for each algorithm:

---

| Algorithm | Number of Words in Result |

| MD5 | 4 Words (128 bits) | | SHA-1 | 5 Words (160 bits) | | SHA-224 | 7 Words (224 bits) |

| SHA-256 | 8 Words (256 bits) |

Returns

None

Definition at line 808 of file shamd5.c.

References _SHAMD5DataWriteMultiple(), ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_CONTEXT_READY, SHAMD5_INT_OUTPUT_READY, SHAMD5_O_IRQSTATUS, SHAMD5HashLengthSet(), and SHAMD5ResultRead().

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);
    ASSERT((ui32DataLength % 64) == 0);

    //
    // Wait for the context to be ready before writing the mode.
    //
    while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_CONTEXT_READY) ==
          0)
    {
    }

    //
    // Write the length.
    //
    SHAMD5HashLengthSet(ui32Base, ui32DataLength);

    //
    // Write the data.
    //
    _SHAMD5DataWriteMultiple(ui32Base, pui32DataSrc, ui32DataLength);

    //
    // Wait for the output to be ready.
    //
    while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_OUTPUT_READY) ==
          0)
    {
    }

    //
    // Read the result.
    //
    SHAMD5ResultRead(ui32Base, pui32HashResult);
}

Here is the call graph for this function:

void SHAMD5DataWrite	(	uint32_t	ui32Base,
		uint32_t *	pui32Src
	)

Perform a blocking write of 16 words of data to the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32Src	is the pointer to the 16-word array of data that will be written.

This function does not return until the module is ready to accept data and the data has been written.

Returns

None.

Definition at line 552 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_INPUT_READY, SHAMD5_O_DATA_0_IN, and SHAMD5_O_IRQSTATUS.

Referenced by _SHAMD5DataWriteMultiple().

{
    uint32_t ui32Counter;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Wait for the module to be ready to accept data.
    //
    while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_INPUT_READY) == 0)
    {
    }

    //
    // Write the 16 words of data.
    //
    for(ui32Counter = 0; ui32Counter < 64; ui32Counter += 4)
    {
        HWREG(ui32Base + SHAMD5_O_DATA_0_IN + ui32Counter) = *pui32Src++;
    }
}

Here is the caller graph for this function:

bool SHAMD5DataWriteNonBlocking	(	uint32_t	ui32Base,
		uint32_t *	pui32Src
	)

Perform a non-blocking write of 16 words of data to the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32Src	is the pointer to the 16-word array of data that will be written.

This function writes 16 words of data into the data register regardless of whether or not the module is ready to accept the data.

Returns

This function returns true if the write completed successfully. It returns false if the module was not ready.

Definition at line 506 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_INPUT_READY, SHAMD5_O_DATA_0_IN, and SHAMD5_O_IRQSTATUS.

{
    uint32_t ui32Counter;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Check that the SHA/MD5 module is ready for data.  If not, return false.
    //
    if((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_INPUT_READY) == 0)
    {
        return(false);
    }

    //
    // Write the 16 words of data.
    //
    for(ui32Counter = 0; ui32Counter < 64; ui32Counter += 4)
    {
        HWREG(ui32Base + SHAMD5_O_DATA_0_IN + ui32Counter) = *pui32Src++;
    }

    //
    // Return true as a sign of successfully completing the function.
    //
    return(true);
}

void SHAMD5DMADisable

(

uint32_t

ui32Base

)

Disables the uDMA requests in the SHA/MD5 module.

Parameters

ui32Base

is the base address of the SHA/MD5 module.

This function configures the DMA options of the SHA/MD5 module.

Returns

None

Definition at line 137 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_O_SYSCONFIG, SHAMD5_SYSCONFIG_DMA_EN, and SHAMD5_SYSCONFIG_SADVANCED.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Write the new configuration into the register.
    //
    HWREG(ui32Base + SHAMD5_O_SYSCONFIG) &=
        ~(SHAMD5_SYSCONFIG_SADVANCED | SHAMD5_SYSCONFIG_DMA_EN);
}

void SHAMD5DMAEnable

(

uint32_t

ui32Base

)

Enables the uDMA requests in the SHA/MD5 module.

Parameters

ui32Base

is the base address of the SHA/MD5 module.

This function configures the DMA options of the SHA/MD5 module.

Returns

None

Definition at line 111 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_O_SYSCONFIG, SHAMD5_SYSCONFIG_DMA_EN, and SHAMD5_SYSCONFIG_SADVANCED.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Write the new configuration into the register.
    //
    HWREG(ui32Base + SHAMD5_O_SYSCONFIG) |=
        SHAMD5_SYSCONFIG_SADVANCED | SHAMD5_SYSCONFIG_DMA_EN;
}

void SHAMD5HashLengthSet	(	uint32_t	ui32Base,
		uint32_t	ui32Length
	)

Write the hash length to the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
ui32Length	is the hash length in bytes.

This function writes the length of the hash data of the current operation to the SHA/MD5 module. The value must be a multiple of 64 if the close hash is not set in the mode register.

Note

When this register is written, hash processing is triggered.

Returns

None.

Definition at line 432 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, and SHAMD5_O_LENGTH.

Referenced by SHAMD5DataProcess(), and SHAMD5HMACProcess().

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Set the LENGTH register and start processing.
    //
    HWREG(ui32Base + SHAMD5_O_LENGTH) = ui32Length;
}

Here is the caller graph for this function:

void SHAMD5HMACKeySet	(	uint32_t	ui32Base,
		uint32_t *	pui32Src
	)

Writes an HMAC key to the digest registers in the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32Src	is the pointer to the 16-word array of the HMAC key.

This function is used to write HMAC key to the digest registers for key preprocessing. The size of pui32Src must be 512 bytes. If the key is less than 512 bytes, then it must be padded with zeros.

Note

It is recommended to use the SHAMD5IntStatus() function to check whether the context is ready before writing the key.

Returns

None

Definition at line 1014 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_MODE_CLOSE_HASH, SHAMD5_MODE_HMAC_KEY_PROC, SHAMD5_MODE_HMAC_OUTER_HASH, SHAMD5_O_MODE, and SHAMD5_O_ODIGEST_A.

{
    uint32_t ui32Idx;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Write the key to the digest registers.
    //
    for(ui32Idx = 0; ui32Idx < 64; ui32Idx += 4)
    {
        HWREG(ui32Base + SHAMD5_O_ODIGEST_A + ui32Idx) = *pui32Src++;
    }

    //
    // Configure the SHA engine for HMAC operation.
    //
    HWREG(ui32Base + SHAMD5_O_MODE) |= (SHAMD5_MODE_HMAC_OUTER_HASH |
                                        SHAMD5_MODE_HMAC_KEY_PROC |
                                        SHAMD5_MODE_CLOSE_HASH);
}

void SHAMD5HMACPPKeyGenerate	(	uint32_t	ui32Base,
		uint32_t *	pui32Key,
		uint32_t *	pui32PPKey
	)

Process an HMAC key using the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32Key	is a pointer to an array that contains the key to be processed.
pui32PPKey	is the pointer to the array that contains the pre-processed key.

This function processes an HMAC key using the SHA/MD5. The resultant pre-processed key can then be used with later HMAC operations to speed processing time.

The pui32Key array must be 16 words (512 bits) long. If the key is less than 512 bits, it must be padded with zeros. The pui32PPKey array must each be 16 words (512 bits) long.

Returns

None

Definition at line 943 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_CONTEXT_READY, SHAMD5_INT_OUTPUT_READY, SHAMD5_MODE_HMAC_KEY_PROC, SHAMD5_O_IRQSTATUS, SHAMD5_O_LENGTH, SHAMD5_O_MODE, and SHAMD5_O_ODIGEST_A.

{
    uint32_t ui32Index;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Wait for the context to be ready before writing the mode.
    //
    while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_CONTEXT_READY) ==
          0)
    {
    }

    //
    // Write the HMAC key.
    //
    for(ui32Index = 0; ui32Index < 64; ui32Index += 4)
    {
        HWREG(ui32Base + SHAMD5_O_ODIGEST_A + ui32Index) = *pui32Key++;
    }

    //
    // Set the flag to cause the HMAC key to be pre-processed.
    //
    HWREG(ui32Base + SHAMD5_O_MODE) |= SHAMD5_MODE_HMAC_KEY_PROC;

    //
    // Set the length to zero to start the HMAC key pre-processing.
    //
    HWREG(ui32Base + SHAMD5_O_LENGTH) = 0;

    //
    // Wait for key to be processed.
    //
    while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_OUTPUT_READY) ==
          0)
    {
    }

    //
    // Read the pre-processed key from the SHA/MD5 module.
    //
    for(ui32Index = 0; ui32Index < 64; ui32Index += 4)
    {
        *pui32PPKey++ = HWREG(ui32Base + SHAMD5_O_ODIGEST_A + ui32Index);
    }
}

void SHAMD5HMACPPKeySet	(	uint32_t	ui32Base,
		uint32_t *	pui32Src
	)

Writes a pre-processed HMAC key to the digest registers in the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32Src	is the pointer to the 16-word array of the HMAC key.

This function is used to write HMAC key to the digest registers for key preprocessing. The size of pui32Src must be 512 bytes. If the key is less than 512 bytes, then it must be padded with zeros.

Note

It is recommended to use the SHAMD5IntStatus() function to check whether the context is ready before writing the key.

Returns

None

Definition at line 1058 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_MODE_CLOSE_HASH, SHAMD5_MODE_HMAC_OUTER_HASH, SHAMD5_O_DIGEST_COUNT, SHAMD5_O_MODE, and SHAMD5_O_ODIGEST_A.

{
    uint32_t ui32Idx;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Write the key to the digest registers.
    //
    for(ui32Idx = 0; ui32Idx < 64; ui32Idx += 4)
    {
        HWREG(ui32Base + SHAMD5_O_ODIGEST_A + ui32Idx) = *pui32Src++;
    }

    //
    // Configure the SHA engine to continue the HMAC.
    //
    HWREG(ui32Base + SHAMD5_O_MODE) |= (SHAMD5_MODE_HMAC_OUTER_HASH |
                                        SHAMD5_MODE_CLOSE_HASH);

    //
    // Write the digest count to 64 to account for the preprocessed key.
    //
    HWREG(ui32Base + SHAMD5_O_DIGEST_COUNT) = 64;
}

void SHAMD5HMACProcess	(	uint32_t	ui32Base,
		uint32_t *	pui32DataSrc,
		uint32_t	ui32DataLength,
		uint32_t *	pui32HashResult
	)

Compute a HMAC with key pre-processing using the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32DataSrc	is a pointer to an array of data that contains the data that is to be hashed.
ui32DataLength	specifies the length of the data to be hashed in bytes.
pui32HashResult	is a pointer to an array that holds the result of the hashing operation.

This function computes a HMAC with the given data using the SHA/MD5 module with a preprocessed key.

The length of the hash result is dependent on the algorithm that is selected with the ui32Algo argument. The following table shows the correct array size for each algorithm:

---

| Algorithm | Number of Words in Result |

| MD5 | 4 Words (128 bits) | | SHA-1 | 5 Words (160 bits) | | SHA-224 | 7 Words (224 bits) |

| SHA-256 | 8 Words (256 bits) |

Returns

None

Definition at line 881 of file shamd5.c.

References _SHAMD5DataWriteMultiple(), ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_CONTEXT_READY, SHAMD5_INT_OUTPUT_READY, SHAMD5_O_IRQSTATUS, SHAMD5HashLengthSet(), and SHAMD5ResultRead().

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Wait for the context to be ready before writing the mode.
    //
    while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_CONTEXT_READY) ==
          0)
    {
    }

    //
    // Write the length.
    //
    SHAMD5HashLengthSet(ui32Base, ui32DataLength);

    //
    // Write the data in the registers.
    //
    _SHAMD5DataWriteMultiple(ui32Base, pui32DataSrc, ui32DataLength);

    //
    // Wait for the output to be ready.
    //
    while((HWREG(ui32Base + SHAMD5_O_IRQSTATUS) & SHAMD5_INT_OUTPUT_READY) ==
          0)
    {
    }

    //
    // Read the result.
    //
    SHAMD5ResultRead(ui32Base, pui32HashResult);
}

Here is the call graph for this function:

void SHAMD5IntClear	(	uint32_t	ui32Base,
		uint32_t	ui32IntFlags
	)

Clears interrupt sources in the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
ui32IntFlags	contains desired interrupts to disable.

ui32IntFlags must be a logical OR of one or more of the following values:

• SHAMD5_INT_CONTEXT_READY - Context input registers are ready.
• SHAMD5_INT_PARTHASH_READY - Context output registers are ready after a context switch.
• SHAMD5_INT_INPUT_READY - Data FIFO is ready to receive data.
• SHAMD5_INT_OUTPUT_READY - Context output registers are ready.

Returns

None.

Definition at line 318 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_CONTEXT_READY, SHAMD5_INT_INPUT_READY, SHAMD5_INT_OUTPUT_READY, SHAMD5_INT_PARTHASH_READY, and SHAMD5_O_DMAIC.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);
    ASSERT((ui32IntFlags == SHAMD5_INT_CONTEXT_READY) ||
           (ui32IntFlags == SHAMD5_INT_PARTHASH_READY) ||
           (ui32IntFlags == SHAMD5_INT_INPUT_READY) ||
           (ui32IntFlags == SHAMD5_INT_OUTPUT_READY));

    //
    // Clear the corresponding flags disabling the interrupt sources.
    //
    HWREG(ui32Base + SHAMD5_O_DMAIC) = (((ui32IntFlags & 0x00010000) >> 14) |
                                        ((ui32IntFlags & 0x00020000) >> 16) |
                                        ((ui32IntFlags & 0x00040000) >> 19));
}

void SHAMD5IntDisable	(	uint32_t	ui32Base,
		uint32_t	ui32IntFlags
	)

Disable interrupt sources in the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
ui32IntFlags	contains desired interrupts to disable.

ui32IntFlags must be a logical OR of one or more of the following values:

• SHAMD5_INT_CONTEXT_READY - Context input registers are ready.
• SHAMD5_INT_PARTHASH_READY - Context output registers are ready after a context switch.
• SHAMD5_INT_INPUT_READY - Data FIFO is ready to receive data.
• SHAMD5_INT_OUTPUT_READY - Context output registers are ready.

Returns

None.

Definition at line 270 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_CONTEXT_READY, SHAMD5_INT_INPUT_READY, SHAMD5_INT_OUTPUT_READY, SHAMD5_INT_PARTHASH_READY, SHAMD5_O_DMAIM, SHAMD5_O_IRQENABLE, SHAMD5_O_SYSCONFIG, and SHAMD5_SYSCONFIG_IT_EN.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);
    ASSERT((ui32IntFlags == SHAMD5_INT_CONTEXT_READY) ||
           (ui32IntFlags == SHAMD5_INT_PARTHASH_READY) ||
           (ui32IntFlags == SHAMD5_INT_INPUT_READY) ||
           (ui32IntFlags == SHAMD5_INT_OUTPUT_READY));

    //
    // Clear the corresponding flags disabling the interrupt sources.
    //
    HWREG(ui32Base + SHAMD5_O_DMAIM) &= ~(((ui32IntFlags & 0x00010000) >> 14) |
                                          ((ui32IntFlags & 0x00020000) >> 16) |
                                          ((ui32IntFlags & 0x00040000) >> 19));
    HWREG(ui32Base + SHAMD5_O_IRQENABLE) &= ~(ui32IntFlags & 0x0000ffff);

    //
    // If there are no interrupts enabled, then disable all interrupts.
    //
    if(HWREG(ui32Base + SHAMD5_O_IRQENABLE) == 0x0)
    {
        HWREG(ui32Base + SHAMD5_O_SYSCONFIG) &= ~SHAMD5_SYSCONFIG_IT_EN;
    }
}

void SHAMD5IntEnable	(	uint32_t	ui32Base,
		uint32_t	ui32IntFlags
	)

Enable interrupt sources in the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
ui32IntFlags	contains desired interrupts to enable.

This function enables interrupt sources in the SHA/MD5 module. ui32IntFlags must be a logical OR of one or more of the following values:

• SHAMD5_INT_CONTEXT_READY - Context input registers are ready.
• SHAMD5_INT_PARTHASH_READY - Context output registers are ready after a context switch.
• SHAMD5_INT_INPUT_READY - Data FIFO is ready to receive data.
• SHAMD5_INT_OUTPUT_READY - Context output registers are ready.

Returns

None.

Definition at line 225 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_INT_CONTEXT_READY, SHAMD5_INT_INPUT_READY, SHAMD5_INT_OUTPUT_READY, SHAMD5_INT_PARTHASH_READY, SHAMD5_O_DMAIM, SHAMD5_O_IRQENABLE, SHAMD5_O_SYSCONFIG, and SHAMD5_SYSCONFIG_IT_EN.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);
    ASSERT((ui32IntFlags == SHAMD5_INT_CONTEXT_READY) ||
           (ui32IntFlags == SHAMD5_INT_PARTHASH_READY) ||
           (ui32IntFlags == SHAMD5_INT_INPUT_READY) ||
           (ui32IntFlags == SHAMD5_INT_OUTPUT_READY));

    //
    // Enable the interrupt sources.
    //
    HWREG(ui32Base + SHAMD5_O_DMAIM) |= (((ui32IntFlags & 0x00010000) >> 14) |
                                         ((ui32IntFlags & 0x00020000) >> 16) |
                                         ((ui32IntFlags & 0x00040000) >> 19));
    HWREG(ui32Base + SHAMD5_O_IRQENABLE) |= ui32IntFlags & 0x0000ffff;

    //
    // Enable all interrupts.
    //
    HWREG(ui32Base + SHAMD5_O_SYSCONFIG) |= SHAMD5_SYSCONFIG_IT_EN;
}

void SHAMD5IntRegister	(	uint32_t	ui32Base,
		void(*)(void)	pfnHandler
	)

Registers an interrupt handler for the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pfnHandler	is a pointer to the function to be called when the enabled SHA/MD5 interrupts occur.

This function registers the interrupt handler in the interrupt vector table, and enables SHA/MD5 interrupts on the interrupt controller; specific SHA/MD5 interrupt sources must be enabled using SHAMD5IntEnable(). The interrupt handler being registered must clear the source of the interrupt using SHAMD5IntClear().

If the application is using a static interrupt vector table stored in flash, then it is not necessary to register the interrupt handler this way. Instead, IntEnable() should be used to enable SHA/MD5 interrupts on the interrupt controller.

See also

IntRegister() for important information about registering interrupt handlers.

Returns

None.

Definition at line 363 of file shamd5.c.

References ASSERT, INT_SHA0_TM4C129, IntEnable(), IntRegister(), and SHAMD5_BASE.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Register the interrupt handler.
    //
    IntRegister(INT_SHA0_TM4C129, pfnHandler);

    //
    // Enable the interrupt
    //
    IntEnable(INT_SHA0_TM4C129);
}

Here is the call graph for this function:

uint32_t SHAMD5IntStatus	(	uint32_t	ui32Base,
		bool	bMasked
	)

Get the interrupt status of the SHA/MD5 module.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
bMasked	is false if the raw interrupt status is required and true if the masked interrupt status is required.

This function returns the current value of the IRQSTATUS register. The value will be a logical OR of the following:

• SHAMD5_INT_CONTEXT_READY - Context input registers are ready.
• SHAMD5_INT_PARTHASH_READY - Context output registers are ready after a context switch.
• SHAMD5_INT_INPUT_READY - Data FIFO is ready to receive data.
• SHAMD5_INT_OUTPUT_READY - Context output registers are ready.

Returns

Interrupt status

Definition at line 172 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_O_DMAMIS, SHAMD5_O_DMARIS, SHAMD5_O_IRQENABLE, and SHAMD5_O_IRQSTATUS.

{
    uint32_t ui32Status, ui32Enable, ui32Temp;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Return the value of the IRQSTATUS register.
    //
    ui32Status = HWREG(ui32Base + SHAMD5_O_IRQSTATUS);
    if(bMasked)
    {
        ui32Enable = HWREG(ui32Base + SHAMD5_O_IRQENABLE);
        ui32Temp = HWREG(ui32Base + SHAMD5_O_DMAMIS);
        return((ui32Status & ui32Enable) |
               ((ui32Temp & 0x00000001) << 19) |
               ((ui32Temp & 0x00000002) << 16) |
               ((ui32Temp & 0x00000004) << 14));
    }
    else
    {
        ui32Temp = HWREG(ui32Base + SHAMD5_O_DMARIS);
        return(ui32Status |
               ((ui32Temp & 0x00000001) << 19) |
               ((ui32Temp & 0x00000002) << 16) |
               ((ui32Temp & 0x00000004) << 14));
    }
}

void SHAMD5IntUnregister

(

uint32_t

ui32Base

)

Unregisters an interrupt handler for the SHA/MD5 module.

Parameters

ui32Base

is the base address of the SHA/MD5 module.

This function unregisters the previously registered interrupt handler and disables the interrupt in the interrupt controller.

See also

IntRegister() for important information about registering interrupt handlers.

Returns

None.

Definition at line 397 of file shamd5.c.

References ASSERT, INT_SHA0_TM4C129, IntDisable(), IntUnregister(), and SHAMD5_BASE.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Disable the interrupt.
    //
    IntDisable(INT_SHA0_TM4C129);

    //
    // Unregister the interrupt handler.
    //
    IntUnregister(INT_SHA0_TM4C129);
}

Here is the call graph for this function:

void SHAMD5Reset

(

uint32_t

ui32Base

)

Resets the SHA/MD5 module.

Parameters

ui32Base

is the base address of the SHA/MD5 module.

This function performs a soft-reset of the SHA/MD5 module using the SYSCONFIG register.

Returns

None.

Definition at line 71 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_O_SYSCONFIG, SHAMD5_O_SYSSTATUS, SHAMD5_SYSCONFIG_SIDLE_FORCE, SHAMD5_SYSCONFIG_SIDLE_M, SHAMD5_SYSCONFIG_SOFTRESET, and SHAMD5_SYSSTATUS_RESETDONE.

{
    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Set the soft-reset bit.
    //
    HWREG(ui32Base + SHAMD5_O_SYSCONFIG) |= SHAMD5_SYSCONFIG_SOFTRESET;

    //
    // Wait for the reset to complete.
    //
    while((HWREG(ui32Base + SHAMD5_O_SYSSTATUS) &
           SHAMD5_SYSSTATUS_RESETDONE) == 0)
    {
    }

    //
    // Force idle mode.
    //
    HWREG(ui32Base + SHAMD5_O_SYSCONFIG) =
        ((HWREG(ui32Base + SHAMD5_O_SYSCONFIG) & ~SHAMD5_SYSCONFIG_SIDLE_M) |
         SHAMD5_SYSCONFIG_SIDLE_FORCE);
}

void SHAMD5ResultRead	(	uint32_t	ui32Base,
		uint32_t *	pui32Dest
	)

Reads the result of a hashing operation.

Parameters

ui32Base	is the base address of the SHA/MD5 module.
pui32Dest	is the pointer to the 16-word array of data that will be written.

This function does not return until the module is ready to accept data and the data has been written.

Returns

None.

Definition at line 592 of file shamd5.c.

References ASSERT, HWREG, SHAMD5_BASE, SHAMD5_MODE_ALGO_M, SHAMD5_MODE_ALGO_MD5, SHAMD5_MODE_ALGO_SHA1, SHAMD5_MODE_ALGO_SHA224, SHAMD5_MODE_ALGO_SHA256, SHAMD5_O_IDIGEST_A, and SHAMD5_O_MODE.

Referenced by SHAMD5DataProcess(), and SHAMD5HMACProcess().

{
    uint32_t ui32Idx, ui32Count;

    //
    // Check the arguments.
    //
    ASSERT(ui32Base == SHAMD5_BASE);

    //
    // Determine the number of bytes in the result, based on the hash type.
    //
    switch(HWREG(ui32Base + SHAMD5_O_MODE) & SHAMD5_MODE_ALGO_M)
    {
        //
        // The MD5 hash is being used.
        //
        case SHAMD5_MODE_ALGO_MD5:
        {
            //
            // There are 16 bytes in the MD5 hash.
            //
            ui32Count = 16;

            //
            // Done.
            //
            break;
        }

        //
        // The SHA-1 hash is being used.
        //
        case SHAMD5_MODE_ALGO_SHA1:
        {
            //
            // There are 20 bytes in the SHA-1 hash.
            //
            ui32Count = 20;

            //
            // Done.
            //
            break;
        }

        //
        // The SHA-224 hash is being used.
        //
        case SHAMD5_MODE_ALGO_SHA224:
        {
            //
            // There are 28 bytes in the SHA-224 hash.
            //
            ui32Count = 28;

            //
            // Done.
            //
            break;
        }

        //
        // The SHA-256 hash is being used.
        //
        case SHAMD5_MODE_ALGO_SHA256:
        {
            //
            // There are 32 bytes in the SHA-256 hash.
            //
            ui32Count = 32;

            //
            // Done.
            //
            break;
        }

        //
        // The hash type is not recognized.
        //
        default:
        {
            //
            // Return without reading a result since the hardware appears to be
            // misconfigured.
            //
            return;
        }
    }

    //
    // Read the hash result.
    //
    for(ui32Idx = 0; ui32Idx < ui32Count; ui32Idx += 4)
    {
        *pui32Dest++ = HWREG(ui32Base + SHAMD5_O_IDIGEST_A + ui32Idx);
    }
}

Here is the caller graph for this function:
