Button I/O library

Macros
#define	button_metadata_init_(_name, _base, _pin, _interrupt)
#define	button_metadata_init(_base, _pin, _interrupt)   button_metadata_init_(button_metadata, _base, _pin, _interrupt)
#define	BUTTON_LEFT   GPIO_PIN_4
#define	BUTTON_RIGHT   GPIO_PIN_0
#define	BUTTONS_BOTH   (BUTTON_LEFT | BUTTON_RIGHT)

Functions
void	button_init (hw_metadata)
void	button_set_interrupt (hw_metadata)

Detailed Description

Macro Definition Documentation

#define BUTTON_LEFT   GPIO_PIN_4

Definition at line 26 of file button.h.

Referenced by postpone_suicide(), and update_pid().

#define button_metadata_init	(		_base,
			_pin,
			_interrupt
	)		button_metadata_init_(button_metadata, _base, _pin, _interrupt)

Create a hardware_metadata struct named `button_metadata'

Definition at line 23 of file button.h.

Referenced by GPIOPortF_Handler(), and main().

#define button_metadata_init_	(		_name,
			_base,
			_pin,
			_interrupt
	)

Value:

hw_metadata _name;                      \
    _name.button = (hw_button_metadata) {           \
    .base     = (memory_address_t) _base,           \
    .pin      = (memory_address_t) _pin,            \
    .interrupt = (uint32_t) _interrupt          \
    }

Create a struct named _name.

Definition at line 13 of file button.h.

#define BUTTON_RIGHT   GPIO_PIN_0

Definition at line 27 of file button.h.

Referenced by postpone_suicide(), and update_pid().

#define BUTTONS_BOTH   (BUTTON_LEFT | BUTTON_RIGHT)

Definition at line 28 of file button.h.

Referenced by button_debounce_end(), button_debounce_start(), GPIOPortF_Handler(), and main().

Function Documentation

void button_init

(

hw_metadata

)

Initialize buttons for use as input.

Note

Currently only supports on-board peripherals.

Definition at line 22 of file button.c.

References hw_metadata::button, GPIO_DIR_MODE_IN, GPIO_LOCK_KEY, GPIO_O_CR, GPIO_O_LOCK, GPIO_PIN_TYPE_STD_WPU, GPIO_PORTF_BASE, GPIO_STRENGTH_2MA, GPIODirModeSet(), GPIOIntEnable(), GPIOPadConfigSet(), HWREG, and hw_button_metadata::pin.

Referenced by hw_driver_init().

                                       {

    GPIODirModeSet(GPIO_PORTF_BASE, metadata.button.pin, GPIO_DIR_MODE_IN);

    HWREG(GPIO_PORTF_BASE + GPIO_O_LOCK) = GPIO_LOCK_KEY;
    HWREG(GPIO_PORTF_BASE + GPIO_O_CR) = 0x01;
    HWREG(GPIO_PORTF_BASE + GPIO_O_LOCK) = 0;

    GPIOPadConfigSet(GPIO_PORTF_BASE, metadata.button.pin,
                     GPIO_STRENGTH_2MA, GPIO_PIN_TYPE_STD_WPU);
    GPIOIntEnable(GPIO_PORTF_BASE, metadata.button.pin);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void button_set_interrupt

(

hw_metadata

)

Subscribe to a hardware interrupt.

Parameters

Hardware

target to subscribe to and isr to invoke upon interrupt

Definition at line 35 of file button.c.

References hw_button_metadata::base, hw_metadata::button, GPIOIntTypeSet(), INT_GPIOF_TM4C123, IntDisable(), IntEnable(), hw_button_metadata::interrupt, and hw_button_metadata::pin.

Referenced by hw_channel_init().

                                                {

    if (metadata.button.interrupt) {
        GPIOIntTypeSet(metadata.button.base,
                       metadata.button.pin,
                       metadata.button.interrupt);
        IntEnable(INT_GPIOF_TM4C123);
    } else {
        IntDisable(INT_GPIOF_TM4C123);
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:
