heartbeat.h File Reference

#include <stdint.h>
#include <stdbool.h>
#include <stdio.h>
#include <stdlib.h>
#include "inc/hw_ints.h"
#include "inc/hw_memmap.h"
#include "driverlib/debug.h"
#include "driverlib/fpu.h"
#include "driverlib/gpio.h"
#include "driverlib/interrupt.h"
#include "driverlib/pin_map.h"
#include "driverlib/sysctl.h"
#include "driverlib/timer.h"
#include "driverlib/rom.h"

Include dependency graph for heartbeat.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Macros
#define	HEART_RED   GPIO_PIN_1
#define	HEART_BLUE   GPIO_PIN_2
#define	HEART_GREEN   GPIO_PIN_3
#define	THORACIC_CAVITY   GPIO_PORTF_BASE
#define	heart_wrap(x)

Functions
void	heart_init ()
	Initialize for visible transformation. More...
int32_t	heart_status ()
	Return the status of . More...
void	heart_off ()
	Turn off. More...
void	heart_on ()
	Turn on. More...
void	heart_toggle ()
	Toggle once. More...
void	heart_beat ()
	Toggle twice. More...

Macro Definition Documentation

#define HEART_BLUE   GPIO_PIN_2

Definition at line 31 of file heartbeat.h.

Referenced by heart_beat(), heart_init(), heart_off(), heart_on(), heart_status(), and heart_toggle().

#define HEART_GREEN   GPIO_PIN_3

Definition at line 32 of file heartbeat.h.

#define HEART_RED   GPIO_PIN_1

The on-board LED colloquially referred to as the 'heart.' Does every computer have one?

Definition at line 30 of file heartbeat.h.

#define heart_wrap

(

x

)

Value:

heart_beat();     \
    x                 \
    heart_toggle();   \

Surround the execution of a code block with two hooks.

• pre_hook: heart_beat();
• post_hook: heart_toggle();

Definition at line 132 of file heartbeat.h.

#define THORACIC_CAVITY   GPIO_PORTF_BASE

The GPIO base where the may be found. Otherwise knows as a subdivision of the ventral body cavity which houses the heart.

Definition at line 37 of file heartbeat.h.

Referenced by heart_beat(), heart_init(), heart_off(), heart_on(), heart_status(), and heart_toggle().

Function Documentation

void heart_beat ( )

inline

Toggle twice.

end_state = starting_state

Returns

void

Definition at line 120 of file heartbeat.h.

References GPIOPinWrite(), HEART_BLUE, heart_status(), and THORACIC_CAVITY.

                  {

#if !(defined(PROFILING_DISABLE))
    GPIOPinWrite(THORACIC_CAVITY, HEART_BLUE, heart_status() ^ HEART_BLUE);
    GPIOPinWrite(THORACIC_CAVITY, HEART_BLUE, heart_status() ^ HEART_BLUE);
#endif
}

Here is the call graph for this function:

void heart_init ( )

inline

Initialize for visible transformation.

Returns

void

Definition at line 49 of file heartbeat.h.

References GPIOPinTypeGPIOOutput(), HEART_BLUE, SYSCTL_PERIPH_GPIOF, SysCtlPeripheralEnable(), and THORACIC_CAVITY.

Referenced by main().

                  {

#if !(defined(PROFILING_DISABLE))
    /* Enable the GPIO port that is used for the on-board LED. */
    SysCtlPeripheralEnable(SYSCTL_PERIPH_GPIOF);

    /* Enable the GPIO pins for the LED (PF2). */
    GPIOPinTypeGPIOOutput(THORACIC_CAVITY, HEART_BLUE);
#endif
}

Here is the call graph for this function:

Here is the caller graph for this function:

void heart_off ( )

inline

Turn off.

Returns

void

Definition at line 79 of file heartbeat.h.

References GPIOPinWrite(), HEART_BLUE, and THORACIC_CAVITY.

                 {

#if !(defined(PROFILING_DISABLE))
    GPIOPinWrite(THORACIC_CAVITY, HEART_BLUE, 0);
#endif
}

Here is the call graph for this function:

void heart_on ( )

inline

Turn on.

Returns

void

Definition at line 92 of file heartbeat.h.

References GPIOPinWrite(), HEART_BLUE, and THORACIC_CAVITY.

                {

#if !(defined(PROFILING_DISABLE))
    GPIOPinWrite(THORACIC_CAVITY, HEART_BLUE, 1);
#endif
}

Here is the call graph for this function:

int32_t heart_status ( )

inline

Return the status of .

Returns

The current status of .

Definition at line 66 of file heartbeat.h.

References GPIOPinRead(), HEART_BLUE, and THORACIC_CAVITY.

Referenced by heart_beat(), and heart_toggle().

                       {

#if !(defined(PROFILING_DISABLE))
    GPIOPinRead(THORACIC_CAVITY, HEART_BLUE);
#endif
}

Here is the call graph for this function:

Here is the caller graph for this function:

void heart_toggle ( )

inline

Toggle once.

end_state = ~starting_state

Returns

void

Definition at line 106 of file heartbeat.h.

References GPIOPinWrite(), HEART_BLUE, heart_status(), and THORACIC_CAVITY.

Referenced by Task1().

                    {

#if !(defined(PROFILING_DISABLE))
    GPIOPinWrite(THORACIC_CAVITY, HEART_BLUE, heart_status() ^ HEART_BLUE);
#endif
}

Here is the call graph for this function:

Here is the caller graph for this function:
