test-priority-scheduler.c File Reference

#include <stdint.h>
#include <stdbool.h>
#include <stdio.h>
#include <stdlib.h>
#include "inc/hw_ints.h"
#include "inc/hw_memmap.h"
#include "driverlib/debug.h"
#include "driverlib/gpio.h"
#include "driverlib/interrupt.h"
#include "driverlib/pin_map.h"
#include "driverlib/sysctl.h"
#include "driverlib/systick.h"
#include "driverlib/rom.h"
#include "libos/os.h"
#include "libheart/heartbeat.h"
#include "libos/semaphore.h"
#include "libtimer/timer.h"
#include "libsystick/systick.h"

Include dependency graph for test-priority-scheduler.c:

Go to the source code of this file.

Macros
#define	HEARTBEAT_MODAL

Functions
void	timer_task ()
void	Task1 ()
void	Task2 ()
void	TIMER0A_Handler (void)
void	main (void)

Variables
uint32_t	PIDWork = 0
semaphore_t	semaphore
uint32_t	interrupt_counter

Macro Definition Documentation

#define HEARTBEAT_MODAL

Definition at line 24 of file test-priority-scheduler.c.

Function Documentation

void main

(

void

)

Definition at line 77 of file test-priority-scheduler.c.

References heart_init(), Hz, INT_TIMER0A, IntEnable(), IntMasterDisable(), IntMasterEnable(), os_add_thread(), os_launch(), OS_SYSTEM_POOL, os_threading_init(), postpone_death, sem_init, semaphore, SYSCTL_OSC_MAIN, SYSCTL_PERIPH_TIMER0, SYSCTL_SYSDIV_1, SYSCTL_USE_OSC, SYSCTL_XTAL_16MHZ, SysCtlClockGet(), SysCtlClockSet(), SysCtlPeripheralEnable(), Task1(), Task2(), TIMER0_BASE, TIMER_A, TIMER_CFG_PERIODIC, timer_metadata_init, TIMER_TIMA_TIMEOUT, TimerConfigure(), TimerEnable(), TimerIntEnable(), and TimerLoadSet().

                {

    SysCtlClockSet(SYSCTL_SYSDIV_1 | SYSCTL_USE_OSC | SYSCTL_OSC_MAIN |
           SYSCTL_XTAL_16MHZ);

    IntMasterDisable();

    heart_init();
    sem_init(semaphore);

    timer_metadata_init(TIMER0_BASE, 1 Hz, INT_TIMER0A, TIMER_CFG_PERIODIC);
    SysCtlPeripheralEnable(SYSCTL_PERIPH_TIMER0);
    TimerConfigure(timer_metadata.timer.base, timer_metadata.timer.periodic);
    TimerLoadSet(timer_metadata.timer.base, TIMER_A, SysCtlClockGet() / timer_metadata.timer.frequency);
    TimerIntEnable(timer_metadata.timer.base, TIMER_TIMA_TIMEOUT);
    IntEnable(timer_metadata.timer.interrupt);
    TimerEnable(timer_metadata.timer.base, TIMER_A);

    os_threading_init(100 Hz);
    os_add_thread(Task1, OS_SYSTEM_POOL);
    os_add_thread(Task2, OS_SYSTEM_POOL);

    IntMasterEnable();
    os_launch();

    postpone_death();
}

Here is the call graph for this function:

void Task1

(

)

Definition at line 40 of file test-priority-scheduler.c.

References FAULT_PENDSV, heart_toggle(), IntPendSet(), semaphore, and semaphore_blocked.

Referenced by main().

             {

    /* Consider: if I can trigger pendsv from an atomic block, will
     * the atomic block be restarted when the context resumes? */
    while(1) {
    /* defun: sem_wait */
    --semaphore;
    while (semaphore_blocked(semaphore)) {
        /* defun: os_surrender_context */
        /* TODO: examine in the context of this not switching to
         * Task2 but instead running the loop endlessly */
        IntPendSet(FAULT_PENDSV);
        /* end_defun */
    }
    /* end_defun */
    heart_toggle();
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void Task2

(

)

Definition at line 59 of file test-priority-scheduler.c.

References PIDWork.

Referenced by main().

             {
    while(1) {
    ++PIDWork;
    }
}

Here is the caller graph for this function:

void TIMER0A_Handler

(

void

)

Definition at line 66 of file test-priority-scheduler.c.

References interrupt_counter, sem_signal, semaphore, TIMER0_BASE, TIMER_TIMA_TIMEOUT, and TimerIntClear().

Referenced by __attribute__().

                           {

    TimerIntClear(TIMER0_BASE, TIMER_TIMA_TIMEOUT);

    /* the task */
    sem_signal(semaphore);
    /* we should see Task1 blink the heartbeat */

    ++interrupt_counter;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void timer_task

(

)

Definition at line 35 of file test-priority-scheduler.c.

References sem_post, semaphore, TIMER0_BASE, TIMER_TIMA_TIMEOUT, and TimerIntClear().

                  {
    TimerIntClear(TIMER0_BASE, TIMER_TIMA_TIMEOUT);
    sem_post(semaphore);
}

Here is the call graph for this function:

Variable Documentation

uint32_t interrupt_counter

Definition at line 33 of file test-priority-scheduler.c.

Referenced by TIMER0A_Handler().

uint32_t PIDWork = 0

Definition at line 31 of file test-priority-scheduler.c.

Referenced by Task2().

semaphore_t semaphore

Definition at line 32 of file test-priority-scheduler.c.

Referenced by main(), Task1(), TIMER0A_Handler(), and timer_task().
